描述
产品简要说明
INTEGRATOR BLOCK 100 22是一款工业级信号集成模块，专为复杂自动化系统设计，支持Modbus、Profinet、EtherCAT等主流工业协议的无缝对接。其核心功能包括：
多协议转换：实现PLC、传感器与执行器的跨系统通信。
实时数据处理：内置FPGA芯片，延迟低于50μs。
模块化扩展：支持最多8个功能子卡混插，适配不同场景需求。
产品详细说明
1.技术架构与创新
硬件设计：
高密度连接：采用PCIe 4.0接口，带宽达16GT/s。
抗干扰结构：屏蔽层+磁环滤波设计，EMC等级符合IEC 61000-6-4。
软件生态：
开源SDK支持：提供Python/C++接口，缩短二次开发周期至7天。
边缘计算能力：集成TensorFlow Lite，支持本地化AI模型推理。
2.工艺适配性
行业场景适配：
汽车制造：兼容KUKA、ABB机器人控制器，实现焊接轨迹动态补偿。
物流分拣：支持视觉传感器与AGV的毫秒级协同控制。
能源管理：与SCADA系统对接，实现电力负载的实时优化调度。
环境适应性：
宽温域运行：-40℃至70℃无风扇设计，MTBF超50万小时。
防尘防水：IP67防护等级，适应室外工况。
技术规格:INTEGRATOR BLOCK 100 22
参数项规格描述
工作电压12-48V DC
协议支持Modbus TCP/RTU,Profinet IO,EtherCAT,MQTT
通信带宽16GT/s（PCIe 4.0）
物理尺寸146mm×102mm×25mm
核心价值与性能亮点
1.智能互联能力
协议融合：单模块支持16个独立通信通道，减少系统级联复杂度。
边缘智能：本地化AI处理降低云端依赖，数据隐私风险降低90%。
2.可靠性设计
冗余机制：双电源输入+看门狗电路，系统故障自恢复时间<100ms。
诊断功能：实时输出通信链路健康度报告，故障定位效率提升80%。
Product brief description
INTEGRATOR BLOCK 100 22 is an industrial-grade signal integration module designed for complex automation systems and supports seamless docking of mainstream industrial protocols such as Modbus,Profinet,and EtherCAT.Its core functions include:
Multi-protocol conversion:realizes cross-system communication between PLC,sensor and actuator.
Real-time data processing:built-in FPGA chip,delay less than 50μs.
Modular expansion:supports up to 8 functional daughter cards mixed and plugged in,adapting to different scenarios.
Product details
1.Technical Architecture and Innovation
Hardware design:
High-density connection:adopts PCIe 4.0 interface,with bandwidth up to 16GT/s.
Anti-interference structure:shielding layer+magnetic ring filtering design,EMC grade complies with IEC 61000-6-4.
Software Ecology:
Open source SDK support:provides Python/C++interface,shortening the secondary development cycle to 7 days.
Edge computing capability:Integrate TensorFlow Lite to support localized AI model inference.
2.Process adaptability
Industry scenario adaptation:
Automobile manufacturing:Compatible with KUKA and ABB robot controllers,realizing dynamic compensation of welding trajectory.
Logistics sorting:Supports millisecond-level coordinated control of vision sensors and AGVs.
Energy management:Docking with the SCADA system to realize real-time optimized scheduling of power loads.
Environmental adaptability:
Wide temperature range operation:-40℃to 70℃fanless design,MTBF exceeds 500,000 hours.
Dust and waterproof:IP67 protection level,adapted to outdoor working conditions.
Technical Specifications:INTEGRATOR BLOCK 100 22
Parameters Specification Description
Working voltage 12-48V DC
Protocol support Modbus TCP/RTU,Profinet IO,EtherCAT,MQTT
Communication bandwidth 16GT/s(PCIe 4.0)
Physical dimensions 146mm×102mm×25mm
Core Valuesand Performance Highlights
1.Intelligent interconnection capability
Protocol fusion:A single module supports 16 independent communication channels,reducing the complexity of system cascade.
Edge Intelligence:Localized AI processing reduces cloud dependence and reduces data privacy risks by 90%.
2.Reliability design
Redundancy mechanism:dual power input+watchdog circuit,system failure self-recovery time<100ms.
Diagnostic function:Real-time output of communication link health report,and the fault positioning efficiency is improved by 80%.
