MAGNETEK 53ST0101-2A00

1.硬件架构设计

核心处理器:

32位RISC-V架构处理器(主频250 MHz)

存储配置:512 KB RAM+8 MB Flash

电源管理:

输入电压:24 VDC(支持冗余供电,转换效率≥92%)

过压保护阈值:36 VDC(响应时间<200μs)

2.功能特性解析

控制算法:

直接转矩控制(DTC)实现±0.2%转速精度

支持多轴同步控制(误差<0.02°)

描述

产品简要说明

MAGNETEK 53ST0101-2A00是MAGNETEK工业自动化产品线中的高性能控制模块,专为复杂工业场景设计,核心特性包括:

多协议兼容:支持EtherCAT、Modbus TCP及CANopen协议

紧凑型设计:尺寸仅120×80×35 mm,适配空间受限环境

宽温域运行:-30℃至70℃工作温度范围

产品详细说明

1.硬件架构设计

核心处理器:

32位RISC-V架构处理器(主频250 MHz)

存储配置:512 KB RAM+8 MB Flash

电源管理:

输入电压:24 VDC(支持冗余供电,转换效率≥92%)

过压保护阈值:36 VDC(响应时间<200μs)

2.功能特性解析

控制算法:

直接转矩控制(DTC)实现±0.2%转速精度

支持多轴同步控制(误差<0.02°)

通信能力:

EtherCAT主站模式(支持100μs周期时间)

Modbus TCP/IP(100 Mbps,支持HTTPS加密通信)

3.工业级可靠性设计

防护机制:

短路保护(响应时间<1 ms)

温度自适应关断(内置PTC热敏电阻)

抗干扰能力:

ESD防护等级:15 kV(空气放电)

EMI抗干扰符合IEC 61000-4-6标准

技术规格:MAGNETEK 53ST0101-2A00

参数项规格描述

额定电流15 A(峰值25 A,10 ms)

通信接口EtherCAT(主站/从站)、Modbus TCP/IP、CANopen(1000 kbps)

工作温度-30℃至70℃

防护等级IP67(防尘防水)

smart

smart

Product brief description

MAGNETEK 53ST0101-2A00 is a high-performance control module in the MAGNETEK industrial automation product line,designed for complex industrial scenarios,and its core features include:

Multi-protocol compatibility:Supports EtherCAT,Modbus TCP and CANopen protocols

Compact design:size is only 120×80×35 mm,adapt to space-constrained environment

Wide temperature range:-30℃to 70℃operating temperature range

Product details

1.Hardware architecture design

Core processor:

32-bit RISC-V architecture processor(main frequency 250 MHz)

Storage configuration:512 KB RAM+8 MB Flash

Power Management:

Input voltage:24 VDC(supports redundant power supply,conversion efficiency≥92%)

Overvoltage protection threshold:36 VDC(response time<200μs)

2.Functional Characteristic Analysis

Control algorithm:

Direct torque control(DTC)achieves±0.2%speed accuracy

Supports multi-axis synchronization control(Error<0.02°)

Communication capability:

EtherCAT master mode(supports 100μs cycle time)

Modbus TCP/IP(100 Mbps,supports HTTPS encrypted communication)

3.Industrial-grade reliability design

Protection mechanism:

Short circuit protection(response time<1 ms)

Temperature adaptive shutdown(built-in PTC thermistor)

Anti-interference ability:

ESD protection level:15 kV(air discharge)

EMI anti-interference complies with IEC 61000-4-6 standard

Technical Specifications:MAGNETEK 53ST0101-2A00

Parameters Specification Description

Rated current 15 A(peak 25 A,10 ms)

Communication interface EtherCAT(master/slave),Modbus TCP/IP,CANopen(1000 kbps)

Operating temperature-30℃to 70℃

Protection level IP67(dust-proof and waterproof)
