MAGNETEK 53SW2003-0000

存储容量:256 KB RAM+4 MB Flash

电源输入:24 VDC(冗余供电,支持热插拔)

扩展接口:

槽位数量:4个,支持功率模块、通信模块、传感器接口混合配置

接口类型:工业级M12连接器

2.核心功能特性

电机控制算法:

矢量控制(FOC)实现±0.3%转速精度

直接转矩控制(DTC)支持快速动态响应(响应时间<50 ms)

通信协议支持:

Modbus RTU(RS485,波特率9600-115200)

Profinet(实时通信,延迟<1 ms)

EtherCAT(主站/从站模式可选)

描述

产品简要说明

MAGNETEK 53SW2003-0000是一款工业级变频器核心控制模块,专为高精度电机驱动系统设计,核心特性包括:

模块化架构:支持灵活扩展功率单元与通信模块

多协议兼容:支持Modbus RTU、Profinet及EtherCAT协议

环境适应性:IP65防护等级,耐受-20℃至60℃工作温度

产品详细说明

1.硬件架构设计

主控单元:

处理器:32位ARM Cortex-M7(主频200 MHz)

存储容量:256 KB RAM+4 MB Flash

电源输入:24 VDC(冗余供电,支持热插拔)

扩展接口:

槽位数量:4个,支持功率模块、通信模块、传感器接口混合配置

接口类型:工业级M12连接器

2.核心功能特性

电机控制算法:

矢量控制(FOC)实现±0.3%转速精度

直接转矩控制(DTC)支持快速动态响应(响应时间<50 ms)

通信协议支持:

Modbus RTU(RS485,波特率9600-115200)

Profinet(实时通信,延迟<1 ms)

EtherCAT(主站/从站模式可选)

3.工业级可靠性设计

防护机制:

过流保护(响应时间<5 ms)

过温关断(支持风扇转速联动散热)

抗干扰能力:

EMI抗干扰等级:Class B(IEC 61000-4-2标准)

ESD防护:8 kV(接触放电)

技术规格:MAGNETEK 53SW2003-0000

参数项规格描述

额定电流20 A(峰值30 A,10 ms)

通信接口Modbus RTU(RS485)、Profinet(100 Mbps)、EtherCAT(100 Mbps)

工作温度-20℃至60℃

防护等级IP65(防尘防水)

Product brief description

MAGNETEK 53SW2003-0000 is an industrial-grade frequency converter core control module designed for high-precision motor drive systems.The core features include:

Modular architecture:Supports flexible expansion of power units and communication modules

Multi-protocol compatibility:Supports Modbus RTU,Profinet and EtherCAT protocols

Environmental adaptability:IP65 protection level,withstands-20℃to 60℃operating temperature

Product details

1.Hardware architecture design

Main control unit:

Processor:32-bit ARM Cortex-M7(main frequency 200 MHz)

Storage capacity:256 KB RAM+4 MB Flash

Power input:24 VDC(redundant power supply,support hot plugging)

Extended interface:

Number of slots:4,support mixed configuration of power module,communication module,sensor interface

Interface type:Industrial grade M12 connector

2.Core functional characteristics

Motor control algorithm:

Vector control(FOC)achieves±0.3%speed accuracy

Direct torque control(DTC)supports fast dynamic response(response time<50 ms)

Communication protocol support:

Modbus RTU(RS485,baud rate 9600-115200)

Profinet(real time communication,delay<1 ms)

EtherCAT(master/slave mode optional)

3.Industrial-grade reliability design

Protection mechanism:

Overcurrent protection(response time<5 ms)

Over-temperature shutdown(supports fan speed linkage heat dissipation)

Anti-interference ability:

EMI anti-interference level:Class B(IEC 61000-4-2 standard)

ESD protection:8 kV(contact discharge)

Technical Specifications:MAGNETEK 53SW2003-0000

Parameters Specification Description

Rated current 20 A(peak 30 A,10 ms)

Communication interface Modbus RTU(RS485),Profinet(100 Mbps),EtherCAT(100 Mbps)

Operating temperature-20℃to 60℃

Protection level IP65(dust-proof and waterproof)
