描述
产品简要说明
Magnetek CIMR-G5M4018是一款专为工业电机设计的高性能变频驱动器，核心特性包括：
宽电压适应：兼容380-480V三相交流电源，支持±10%电压波动容忍度
节能模式：内置自适应负载检测算法，待机功耗降低30%
高功率因数：接近整数功率因数（P.F.≥0.95），减少电力损耗
产品详细说明
1.核心技术架构
矢量控制技术：
支持磁场定向控制（FOC）与转差频率控制（SVC）双模式切换
转矩响应时间≤10ms，适用于高动态负载场景（如离心泵、压缩机）
多协议通信：
支持Modbus TCP/IP、Profinet、EtherCAT等工业协议
实时数据传输速率≥100Mbps，支持分布式系统协同控制
2.硬件设计亮点
散热系统：
采用双风扇强制风冷设计，热阻≤0.25℃/W
防护等级IP55，适应-20℃至50℃环境温度
抗干扰能力：
通过IEC 61000-6-2工业级EMC认证
支持±20%电压波动容忍度，适应恶劣电网环境
3.智能运维功能
预测性维护：
实时监测电机绕组温度、轴承振动频率
通过云平台远程上传设备状态数据，支持故障预警
自诊断功能：
内置100+故障代码库，支持快速定位问题
通过LED指示灯与显示屏双重反馈故障信息
技术规格:Magnetek CIMR-G5M4018
参数项规格描述
输入电压380-480V三相交流电（50/60Hz）
输出功率15kW（连续运行）
控制精度转速精度±0.1%，转矩精度±1%
防护等级IP55（防尘防水）
通信接口2×千兆以太网端口、1×RS-485端口
谐波抑制总谐波畸变率（THDI）≤8%，无需额外滤波器
核心价值与性能亮点
1.高效节能
案例：在纺织厂卷绕机应用中，通过变频调速技术年节电约25%。
2.高可靠性
优势：通过10,000小时连续运行测试，故障率低于0.1%。
3.快速部署
功能：支持预设参数模板（如风机、水泵、压缩机），单台设备调试时间≤1小时。
Product brief description
Magnetek CIMR-G5M4018 is a high-performance variable frequency driver designed for industrial motors,with core features including:
Wide voltage adaptation:compatible with 380-480V three-phase AC power supply,support±10%voltage fluctuation tolerance
Energy-saving mode:built-in adaptive load detection algorithm,standby power consumption reduced by 30%
High power factor:close to integer power factor(P.F.≥0.95),reducing power loss
Product details
1.Core technology architecture
Vector control technology:
Supports dual mode switching between magnetic field directional control(FOC)and slip frequency control(SVC)
Torque response time≤10ms,suitable for high dynamic load scenarios(such as centrifugal pumps,compressors)
Multi-protocol communication:
Supports industrial protocols such as Modbus TCP/IP,Profinet,EtherCAT,etc.
Real-time data transmission rate≥100Mbps,supports distributed system collaborative control
2.Highlights of hardware design
Heat dissipation system:
Adopt a dual fan forced air cooling design,thermal resistance≤0.25℃/W
Protection level IP55,adapts to ambient temperature of-20℃to 50℃
Anti-interference ability:
Passed IEC 61000-6-2 Industrial EMC certification
Supports±20%voltage fluctuation tolerance and adapts to harsh power grid environments
3.Intelligent operation and maintenance functions
Predictive maintenance:
Real-time monitoring of motor winding temperature and bearing vibration frequency
Remote upload of device status data through cloud platform to support fault warning
Self-diagnosis function:
Built-in 100+fault code library,supports quick problem locating
The fault information is double feedback through the LED indicator and the display screen
Technical Specifications:Magnetek CIMR-G5M4018
Parameters Specification Description
Input voltage 380-480V three-phase alternating current(50/60Hz)
Output power 15kW(continuous operation)
Control accuracy Speedaccuracy±0.1%,torque accuracy±1%
Protection level IP55(dust-proof and waterproof)
Communication interface 2×Gigabit Ethernet port,1×RS-485 port
Harmonic Suppression Total Harmonic Distortion Rate(THDI)≤8%,no additional filter required
Core Valuesand Performance Highlights
1.High efficiency and energy saving
Case:In the application of textile factory winding machines,the annual power saving is about 25%through frequency conversion speed regulation technology.
2.High reliability
Advantages:Passed 10,000 hours of continuous running tests,the failure rate is less than 0.1%.
3.Rapid deployment
Function:Supports preset parameter templates(such as fans,water pumps,compressors),and the debugging time of a single device is≤1 hour.
