描述
产品简要说明
Magnetek EDB4065DT是一款专为永磁同步电机（PMSM）设计的智能驱动控制器，核心特性包括：
高效能控制：支持磁场定向控制（FOC）技术，实现动态转矩与转速精准调节
宽电压适应：兼容380-480V三相交流电源，适应工业电网波动
智能节能模式：通过自适应负载检测技术降低待机功耗
产品详细说明
1.核心技术架构
磁场定向控制（FOC）：
基于矢量控制算法，实现±0.1%的转速精度与±1%的转矩控制
支持无编码器传感器模式，降低系统复杂度
再生能量管理：
内置主动整流单元，将再生能量回馈至电网或储能系统
能耗降低率可达15-25%，符合IEC 60034-30-1能效标准
2.硬件设计亮点
模块化散热结构：
采用交叉风道设计，热阻降低至0.25℃/W，支持50℃环境温度连续运行
可选配液冷扩展模块（兼容EDB4065DT-LC），适用于高负载场景
抗干扰能力：
通过CE认证EMC等级（EN 61000-6-2工业环境标准）
支持±20%电压波动容忍度
3.智能诊断与通信
预测性维护功能：
实时监测电机绕组温度、轴承振动频率，支持故障模式分析
通过Modbus TCP/IP协议上传至云平台，实现远程运维
多语言编程界面：
支持Magnetek Drive Configurator软件，提供中英文操作界面
预设50+行业应用参数模板（如泵类、风机、压缩机）
技术规格:Magnetek EDB4065DT
参数项规格描述
输入电压380-480V三相交流电（50/60Hz）
输出功率5.5-15kW（根据电机型号可扩展至22kW）
防护等级IP55（防尘防水）
通信接口1×RS-485（Modbus RTU）、1×千兆以太网（Modbus TCP/IP）
环境湿度10-95%（非凝露）
核心价值与性能亮点
1.节能优化
案例：在污水处理厂离心泵应用中，通过自适应节能模式年节电约18%。
2.高可靠性
优势：在-20℃至50℃温度范围内保持±0.5%的控制精度，适用于极端环境。
3.快速部署
功能：预装行业标准参数模板，单台设备调试时间缩短至2小时内。
Product brief description
The Magnetek EDB4065DT is an intelligent drive controller designed for permanent magnet synchronous motors(PMSMs).The core features include:
High-performance control:Supports magnetic field directional control(FOC)technology to achieve accurate adjustment of dynamic torque and speed
Wide voltage adaptation:compatible with 380-480V three-phase AC power supply,adapting to industrial power grid fluctuations
Intelligent energy-saving mode:reduce standby power consumption through adaptive load detection technology
Product details
1.Core technology architecture
Magnetic Field Orientation Control(FOC):
Based on the vector control algorithm,the speed accuracy of±0.1%and the torque control of±1%are achieved.
Supports encoder-free sensor mode to reduce system complexity
Regeneration energy management:
Built-in active rectifier unit to feed regenerated energy back to the power grid or energy storage system
Energy consumption reduction rate can reach 15-25%,comply with IEC 60034-30-1 energy efficiency standard
2.Highlights of hardware design
Modular heat dissipation structure:
Adopt the cross-channel design,the thermal resistance is reduced to 0.25℃/W,and supports continuous operation of 50℃ambient temperature
Optional liquid-cooled expansion module(compatible with EDB4065DT-LC),suitable for high load scenarios
Anti-interference ability:
Passed CE certification EMC grade(EN 61000-6-2 Industrial Environmental Standard)
Supports±20%voltage fluctuation tolerance
3.Intelligent diagnostics and communications
Predictive maintenance features:
Real-time monitoring of motor winding temperature and bearing vibration frequency,supporting fault mode analysis
Upload to the cloud platform through Modbus TCP/IP protocol to realize remote operation and maintenance
Multilingual programming interface:
Supports Magnetek Drive Configurator software and provides Chinese and English operating interfaces
Preset 50+industry application parameter templates(such as pumps,fans,compressors)
Technical Specifications:Magnetek EDB4065DT
Parameters Specification Description
Input voltage 380-480V three-phase alternating current(50/60Hz)
Output power 5.5-15kW(scalable to 22kW depending on the motor model)
Protection level IP55(dust-proof and waterproof)
Communication interface 1×RS-485(Modbus RTU),1×Gigabit Ethernet(Modbus TCP/IP)
Ambient humidity 10-95%(non-condensing)
Core Valuesand Performance Highlights
1.Energy saving optimization
Case:In the application of centrifugal pumps in sewage treatment plants,the annual electricity saving is about 18%through the adaptive energy saving mode.
2.High reliability
Advantages:Maintain±0.5%control accuracy within the temperature range of-20℃to 50℃,suitable for extreme environments.
3.Rapid deployment
Function:Preinstalled industry standard parameter templates,shorten the debugging time of a single device to within 2 hours.
