描述
MAGNETEK HP4-1D-T-S1139是一款电源模块，也称为单输出电源。它主要设计用于为分布式电源系统提供前端支持。
主要功能与应用
电源转换：将输入的交流电（AC）或直流电（DC）转换为系统所需的稳定直流电。
分布式电源系统：该模块作为前端设备，为电信网络、数据存储系统、高端服务器、医疗和工业产品等设备提供可靠的电源。
热插拔能力：它具备热插拔功能，这对于需要高可用性和不间断运行的关键系统非常重要。
N+1冗余：支持N+1热插拔，通常包含一个或多个ORing二极管，以确保在某个模块发生故障时，系统仍能继续供电。
技术规格
型号系列：属于HP3/4系列单输出电源。
输入电压：100-240 VAC（宽范围交流输入），支持50/60 Hz。
最大直流输出功率：500 W。
输出电压：12 VDC。
输出电流：40 A。
特性：
功率因数校正。
5 V待机输出。
单线电流共享。
无最小负载要求。
The MAGNETEK HP4-1D-T-S1139 is a power supply module,also known as a single-output power supply.It is primarily designed to provide front-end support for distributed power systems.
Main Functions and Applications
Power Conversion:Converts input alternating current(AC)or direct current(DC)into the stable DC power required by the system.
Distributed power systems:This module serves as a front-end device,providing reliable power to equipment such as telecommunications networks,data storage systems,high-end servers,and medical and industrial products.
Hot-Swap Capability:It features hot-swap functionality,which is crucial for critical systems requiring high availability and uninterrupted operation.
N+1 Redundancy:Supports N+1 hot-swap functionality and typically includes one or more ORing diodes to ensure continued system power supply in the event of a module failure.
Technical Specifications
Model Series:Belongs to the HP3/4 series of single-output power supplies.
Input Voltage:100-240 VAC(wide-range AC input),supporting 50/60 Hz.
Maximum DC Output Power:500 W.
Output voltage:12 VDC.
Output current:40 A.
Features:
Power factor correction.
5 V standby output.
Single-line current sharing.
No minimum load requirement.
