MAGNETEK YPHT11017-1B

分类: 品牌:

描述

产品简要说明

MAGNETEK YPHT11017-1B是一款工业级温度变送器模块,专为复杂工业环境设计,核心特性包括:

高精度信号处理:支持热电偶/热电阻双输入模式

宽温域适应性:-40℃至+85℃稳定运行

智能校准功能:支持零点漂移自动补偿

产品详细说明

1.核心工作原理

信号调理技术:

采用24位Σ-ΔADC(分辨率0.01℃)

隔离放大器设计(共模抑制比>100 dB)

抗干扰机制:

数字滤波算法(采样频率100 Hz)

双重屏蔽层(EMI抗干扰等级Class B)

2.硬件设计解析

结构特性:

密封等级IP67(防尘防水)

安装方式:导轨式安装(符合DIN 35mm标准)

电气接口:

输入范围:-200℃至+1700℃(热电偶K型)

输出信号:4-20mA隔离输出(负载≤750Ω)

3.环境适应性优化

温度管理:

自适应热补偿算法(-40℃至+85℃误差<±0.5℃)

耐腐蚀涂层(符合IEC 60068-2-60标准)

机械强度:

振动耐受:5-500 Hz(加速度5g)

冲击测试:50g/11ms(符合MIL-STD-810G)

技术规格:MAGNETEK YPHT11017-1B

参数项规格描述

输入类型热电偶(K/J/S/R/T)或热电阻(Pt100/Pt1000)

测量精度±0.2℃(-20℃至+300℃范围)

响应时间≤200 ms

工作温度-40℃至+85℃

防护等级IP67(防尘防水)

核心价值与性能亮点

1.高精度测温优势

应用场景:

替代传统分立式温度测量系统,减少信号失真

在冶金炉温控中实现±0.5℃精度控制

2.极端环境可靠性

高温适应性:

在水泥窑环境中连续运行1000小时无故障

湿热环境(RH 95%)下湿度补偿算法自动校准

Product brief description

MAGNETEK YPHT11017-1B is an industrial-grade temperature transmitter module designed for complex industrial environments,with core features including:

High-precision signal processing:Supports thermocouple/thermoresistor dual input mode

Wide temperature domain adaptability:-40℃to+85℃stable operation

Intelligent calibration function:supports automatic compensation for zero-point drift

Product details

1.Core working principle

Signal conditioning technology:

Use 24-bitΣ-ΔADC(resolution 0.01℃)

Isolation amplifier design(common mode rejection ratio>100 dB)

Anti-interference mechanism:

Digital filtering algorithm(sampling frequency 100 Hz)

Double shielding layer(EMI anti-interference level Class B)

2.Hardware design analysis

Structural characteristics:

Sealing grade IP67(dust-proof and waterproof)

Installation method:Rail-type installation(compliant with DIN 35mm standard)

Electrical interface:

Input range:-200℃to+1700℃(thermocouple K-type)

Output signal:4-20mA isolated output(load≤750Ω)

3.Environmental adaptability optimization

Temperature management:

Adaptive thermal compensation algorithm(Error of-40℃to+85℃<±0.5℃)

Corrosion-resistant coating(compliant with IEC 60068-2-60)

Mechanical strength:

Vibration resistance:5-500 Hz(acceleration 5g)

Impact test:50g/11ms(compliant with MIL-STD-810G)

Technical Specifications:MAGNETEK YPHT11017-1B

Parameters Specification Description

Input type Thermocouple(K/J/S/R/T)or thermoresistor(Pt100/Pt1000)

Measurement accuracy±0.2℃(-20℃to+300℃range)

Response time≤200 ms

Operating temperature-40℃to+85℃

Protection level IP67(dust-proof and waterproof)

Core Values​​and Performance Highlights

1.Advantages of high-precision temperature measurement

Application scenarios:

Replace traditional discrete temperature measurement systems to reduce signal distortion

Achieve±0.5℃accuracy control in metallurgical furnace temperature control

2.Extreme environmental reliability

High temperature adaptability:

Run continuously for 1000 hours in cement kiln environment without trouble

Automatic calibration of humidity compensation algorithm in humid and heat environment(RH 95%)
