描述
产品简要说明
Marposs 6307351602是马波斯（MARPOSS）专为高速数控机床开发的微型测头，采用五轴同步补偿算法与陶瓷复合探针，支持刀具磨损在机监测与工件尺寸闭环修正，显著提升复杂型面加工精度。
产品详细说明
五轴联动适配技术
实时运动补偿
惯性预测模型：通过加速度传感器预判机床运动趋势（响应延迟<0.5ms）。
矢量力平衡：探针受力分解算法降低振颤干扰（抑制率85%）。
微型化结构设计
陶瓷复合探针：直径φ3mm（传统同类产品φ5mm）。
嵌入式安装：适配BT40/HSK-A63主轴接口（突入量≤8mm）
智能诊断功能
刀具寿命预测：基于切削力变化趋势生成剩余寿命曲线（误差±3%）
自清洁机制：压缩空气脉冲清除切屑（频率50Hz）。
产品概述:Marposs 6307351602
作为MicroCheck系列的革新之作，其五轴联动适配技术与微型化探针设计，突破了叶轮、涡轮等复杂曲面加工中“测量空间受限”的行业瓶颈，实现加工精度与效率的双重提升。
技术规格:Marposs 6307351602
参数类别技术指标
测量范围±0.2mm（可扩展至±0.5mm）
触发力0.1-1.5N（六档可调）
工作温度-20℃～+80℃（温漂系数0.001%/℃）
通信协议RS-232（标准）/TCP/IP（选配）
Product brief description
Marposs 6307351602 is a miniature probe developed by MARPOSS for high-speed CNC machine tools.It uses a five-axis synchronous compensation algorithm and ceramic composite probe to support tool wear monitoring and closed-loop correction of workpiece size,significantly improving the accuracy of complex profile processing.
Product details
Five-axis linkage adaptation technology
Real-time motion compensation
Inertial prediction model:predict the machine tool motion trend through acceleration sensor(response delay<0.5ms).
Vector force balance:The probe force decomposition algorithm reduces vibration interference(suppression rate 85%).
Miniaturized structure design
Ceramic composite probe:diameterφ3mm(traditional similar productsφ5mm).
Embedded installation:adapted to BT40/HSK-A63 spindle interface(projection amount≤8mm)
Intelligent diagnostic function
Tool life prediction:Generate residual life curve based on cutting force change trend(Error±3%)
Self-cleaning mechanism:compressed air pulse to remove chips(frequency 50Hz).
Product Overview:Marposs 6307351602
As an innovative work of the MicroCheck series,its five-axis linkage adaptation technology and miniaturized probe design break through the industry bottleneck of”constrained measurement space”in complex surface processing such as impellers and turbines,and achieves the dual improvement of processing accuracy and efficiency.
Technical Specifications:Marposs 6307351602
Parameter category Technical indicators
Measuring range±0.2mm(expandable to±0.5mm)
Trigger force 0.1-1.5N(six gear adjustable)
Working temperature-20℃～+80℃(temperature drift coefficient 0.001%/℃)
Communication Protocol RS-232(Standard)/TCP/IP(Optional)
