描述
一、产品定位与核心优势
1.品牌与产品线归属
MECS（工业传感器与自动化设备品牌）：
UTX101001是MECS品牌旗下的一款高精度工业级压力/温度复合传感器，专注于液体或气体介质的压力、温度同步监测，适用于液压系统、过程控制、能源管理等领域。
核心优势：
双参数集成：单设备同时测量压力与温度，减少安装空间与成本。
高精度与稳定性：压力测量精度达±0.1%FS，温度精度±0.5℃，满足精密控制需求。
工业级防护：具备IP68防护等级，适应水下、高压、腐蚀性介质等恶劣环境。
智能通信：支持4-20mA、RS485（Modbus RTU）、HART协议，兼容PLC、DCS、SCADA系统。
2.典型应用场景
液压与气动系统：
液压机压力监控：实时检测液压油压力与温度，防止系统过热或过压损坏。
气动阀门控制：通过压力反馈调节阀门开度，确保气流稳定性。
过程工业（化工、石油天然气）：
管道压力监测：在输油/输气管道中检测介质压力变化，预防泄漏或爆管事故。
反应釜温度控制：同步监测釜内压力与温度，优化化学反应条件。
能源与水务：
水泵效率分析：通过压力与温度数据计算水泵扬程与能耗，提升系统能效。
供水管道监测：检测水压波动，辅助漏损定位与爆管预警。
二、技术参数详解
1.基础规格
参数类别规格详情
型号MECS UTX101001
系列MECS Universal Transmitter Series（通用型变送器系列）
安装方式螺纹安装（G1/2、NPT1/2可选）或法兰安装（DN15-DN50）
外壳材质316L不锈钢（耐腐蚀）或哈氏合金（C-276，强腐蚀介质）
防护等级IP68（防尘、防水浸，可短期潜水）
尺寸（L×D）120×50 mm（不含安装接头）
重量约0.8 kg
1.Product positioning and core advantages
1.Brand and product line ownership
MECS(industrial sensor and automation equipment brand):
UTX101001 is a high-precision industrial-grade pressure/temperature composite sensor under the MECS brand,focusing on the simultaneous monitoring of pressure and temperature of liquid or gas media,suitable for hydraulic systems,process control,energy management and other fields.
Core advantages:
Dual parameter integration:a single device measures pressure and temperature at the same time,reducing installation space and cost.
High precision and stability:pressure measurement accuracy of±0.1%FS,temperature accuracy of±0.5℃,meeting precision control requirements.
Industrial protection:with IP68 protection level,suitable for harsh environments such as underwater,high pressure,corrosive media,etc.
Intelligent communication:supports 4-20mA,RS485(Modbus RTU),HART protocols,compatible with PLC,DCS,SCADA systems.
2.Typical application scenarios
Hydraulic and pneumatic systems:
Hydraulic press pressure monitoring:Real-time detection of hydraulic oil pressure and temperature to prevent system overheating or overpressure damage.
Pneumatic valve control:Adjust valve opening through pressure feedback to ensure airflow stability.
Process industry(chemical,oil and gas):
Pipeline pressure monitoring:Detect medium pressure changes in oil/gas pipelines to prevent leakage or pipe burst accidents.
Reactor temperature control:Synchronously monitor the pressure and temperature in the reactor to optimize chemical reaction conditions.
Energy and water:
Pump efficiency analysis:Calculate pump head and energy consumption through pressure and temperature data to improve system energy efficiency.
Water supply pipeline monitoring:Detect water pressure fluctuations,assist in leakage location and pipe burst warning.
2.Technical Parameters
1.Basic Specifications
Parameter Category Specification Details
Model MECS UTX101001
Series MECS Universal Transmitter Series(Universal Transmitter Series)
Installation method Threaded installation(G1/2,NPT1/2 optional)or Flange installation(DN15-DN50)
Housing material 316L stainless steel(corrosion resistant)or Hastelloy(C-276,highly corrosive media)
Protection level IP68(dustproof,waterproof,short-term diving)
Dimensions(L×D)120×50 mm(excluding mounting connector)
Weight Approximately 0.8 kg
