描述
产品简要说明
Metso B1JU835L是一款工业级高密度连接器套件，核心功能包括：
严苛环境适应性：IP67防护等级，耐受-65℃至200℃极端温度
高可靠性设计：500次插拔循环寿命，化学镀镍/金铝壳镀层
信号保护：EMI凸点或RFI弹簧夹屏蔽选项
兼容性：支持MIL-DTL-24308标准，与M24308型连接器互配
产品详细说明
1.技术架构与功能特性
物理结构：
接口类型：D型高密度插针/插孔设计，支持多芯信号传输
材料特性：航空级铝合金壳体，表面镀层可选化学镀镍或金
环境适应性：
温度管理：-65℃至200℃工作范围，通过EN 61000-3-2认证
密封设计：双层O型圈密封，防护等级IP67（防尘防水）
2.信号处理与防护
屏蔽方案：
EMI/RFI抑制：可选EMI凸点或RFI弹簧夹屏蔽结构
抗干扰能力：符合MIL-STD-461F标准，抑制电磁干扰≥60dB
电气性能：
接触电阻：≤5mΩ（常温下）
绝缘电阻：≥10^12Ω（500V DC测试）
3.工业应用适配性
安装方式：
支持板对板、线对板两种安装模式
固定螺栓M4不锈钢材质，耐腐蚀等级316L
维护特性：
快速插拔设计，支持热插拔操作
状态指示：LED显示连接/断开状态
技术规格:Metso B1JU835L
参数项规格描述
接口类型D型高密度连接器（针数可定制，最大支持64芯）
温度范围-65℃至200℃
防护等级IP67（防尘防水）
插拔寿命≥500次循环
屏蔽选项EMI凸点/RFI弹簧夹（可选）
核心价值与性能亮点
1.航天级可靠性
技术突破：某卫星通信系统采用B1JU835L后，信号传输稳定性提升至99.99%
2.极端环境适应性
场景案例：在北极科考站设备中，模块在-60℃环境下连续运行2年无性能衰减
Product brief description
Metso B1JU835L is an industrial-grade high-density connector kit with core features including:
Strict environmental adaptability:IP67 protection level,withstand extreme temperatures of-65℃to 200℃
High reliability design:500 plug-in and unplugging cycle life,electroless nickel/gold aluminum shell plating
Signal protection:EMI bump or RFI spring clip shielding option
Compatibility:Supports MIL-DTL-24308 standard and matches with M24308 type connectors
Product details
1.Technical architecture and functional characteristics
Physical structure:
Interface type:D-type high-density pin/jack design,supports multi-core signal transmission
Material characteristics:aviation grade aluminum alloy shell,surface plating can be electroless nickel or gold plating
Environmental adaptability:
Temperature management:working range of-65℃to 200℃,passed EN 61000-3-2 certification
Sealing design:double-layer O-ring seal,protection level IP67(dust-proof and waterproof)
2.Signal processing and protection
Blocking solution:
EMI/RFI suppression:optional EMI bump or RFI spring clip shielding structure
Anti-interference ability:complies with MIL-STD-461F standard,suppresses electromagnetic interference≥60dB
Electrical performance:
Contact resistance:≤5mΩ(at room temperature)
Insulation resistance:≥10^12Ω(500V DC test)
3.Adaptability for industrial applications
Installation method:
Supports two installation modes:board-to-board and line-to-board
Fixing bolts M4 stainless steel,corrosion resistance grade 316L
Maintenance features:
Quick plug-and-unplug design,support hot plug-and-unplug operation
Status indicator:LED displays connected/disconnected status
Technical Specifications:Metso B1JU835L
Parameters Specification Description
Interface type D-type high-density connector(the number of pins can be customized,and the maximum support is 64 cores)
Temperature range-65℃to 200℃
Protection level IP67(dust-proof and waterproof)
Plug-out life≥500 cycles
Shielding Options EMI bump/RFI spring clip(optional)
Core Valuesand Performance Highlights
1.Aerospace-level reliability
Technical breakthrough:After a satellite communication system adopts B1JU835L,the signal transmission stability has been improved to 99.99%
2.Extreme environmental adaptability
Scenario case:In the Arctic scientific research station equipment,the module operates continuously in-60℃for 2 years without performance attenuation
