METSO BOU84 A413154

1.技术架构与核心功能

控制单元特性:

处理器配置:双核ARM Cortex-R5F,主频800MHz,支持实时操作系统(RTOS)

内存架构:512MB DDR4+4GB SSD,支持固件在线升级

通信能力:

工业总线:2×EtherCAT主站端口(RJ45)、1×Profinet接口(100Mbps)

协议兼容性:内置OPC UA客户端,支持与maxDNA系统实时数据交互

I/O扩展:

模拟量接口:32通道16位ADC(±10V/4-20mA),采样率10kHz

数字量接口:16路DI(24VDC)+16路DO(24VDC/1A)

2.工业级可靠性设计

抗干扰能力:

电磁兼容性:符合IEC 61000-4-2/-4-5标准,抗ESD达±25kV

信号隔离:模拟量通道隔离电压≥4kV,数字量通道隔离电压≥2.5kV

环境适应性:

宽温运行:-30°C至70°C(工作)/-40°C至85°C(存储)

防护等级:IP65(防尘防水),适用于户外/潮湿环境

3.行业应用适配性

特殊模块扩展:

安全控制:可集成SIL 2认证安全模块(需外接F3NC32-0N定位器)

能源管理:支持功率因数补偿(PFC)算法,适用于电力系统优化

技术规格:METSO BOU84 A413154

分类: 品牌:

描述

产品简要说明

METSO BOU84 A413154是一款专为Metso maxDNA分散控制系统设计的高精度I/O扩展模块,核心功能包括:

多协议兼容:支持EtherCAT、Profinet、Modbus TCP/IP协议,无缝集成maxDNA系统

工业级可靠性:IP65防护等级,宽温运行(-30°C至70°C)

高密度模拟量扩展:单模块支持32通道16位ADC(±10V/4-20mA)

动态信号处理:内置抗混叠滤波器与信号补偿算法,确保工业环境下的精度

产品详细说明

1.技术架构与核心功能

控制单元特性:

处理器配置:双核ARM Cortex-R5F,主频800MHz,支持实时操作系统(RTOS)

内存架构:512MB DDR4+4GB SSD,支持固件在线升级

通信能力:

工业总线:2×EtherCAT主站端口(RJ45)、1×Profinet接口(100Mbps)

协议兼容性:内置OPC UA客户端,支持与maxDNA系统实时数据交互

I/O扩展:

模拟量接口:32通道16位ADC(±10V/4-20mA),采样率10kHz

数字量接口:16路DI(24VDC)+16路DO(24VDC/1A)

2.工业级可靠性设计

抗干扰能力:

电磁兼容性:符合IEC 61000-4-2/-4-5标准,抗ESD达±25kV

信号隔离:模拟量通道隔离电压≥4kV,数字量通道隔离电压≥2.5kV

环境适应性:

宽温运行:-30°C至70°C(工作)/-40°C至85°C(存储)

防护等级:IP65(防尘防水),适用于户外/潮湿环境

3.行业应用适配性

特殊模块扩展:

安全控制:可集成SIL 2认证安全模块(需外接F3NC32-0N定位器)

能源管理:支持功率因数补偿(PFC)算法,适用于电力系统优化

技术规格:METSO BOU84 A413154

参数项规格描述

处理器双核ARM Cortex-R5F,主频800MHz

内存512MB DDR4+4GB SSD

通信接口2×EtherCAT(RJ45)+1×Profinet(RJ45)+1×RS-485(Modbus RTU)

I/O通道32点模拟量(±10V/4-20mA)+32点数字量(DI/DO)

工作温度-30℃至70℃

防护等级IP65(标准配置)

核心价值与性能亮点

1.高精度模拟量采集

技术突破:16位ADC分辨率+抗混叠滤波器,确保±0.1%精度,适用于汽轮机振动监测等场景

2.动态环境适应性

场景适配:在70°C高温环境下仍保持100%运行可靠性,适用于火力发电厂、化工装置等

应对挑战,创造价值

1.传统模拟量模块精度不足

技术突破:通过自适应温度补偿算法,消除环境温度对测量的影响

2.复杂系统通信延迟

场景案例:某大型发电厂采用BOU84 A413154后,模拟量数据传输延迟降低至1ms

Product brief description

METSO BOU84 A413154 is a high-precision I/O expansion module designed for Metso maxDNA dispersion control system.The core functions include:

Multi-protocol compatibility:supports EtherCAT,Profinet,Modbus TCP/IP protocols,seamlessly integrates maxDNA system

Industrial-grade reliability:IP65 protection grade,wide temperature operation(-30°C to 70°C)

High-density analog expansion:Single module supports 32-channel 16-bit ADC(±10V/4-20mA)

Dynamic signal processing:built-in anti-aliasing filter and signal compensation algorithm to ensure accuracy in industrial environments

Product details

1.Technical architecture and core functions

Control unit features:

Processor configuration:Dual-core ARM Cortex-R5F,main frequency of 800MHz,support real-time operating system(RTOS)

Memory architecture:512MB DDR4+4GB SSD,support online firmware upgrade

Communication capability:

Industrial bus:2×EtherCAT master port(RJ45),1×Profinet interface(100Mbps)

Protocol compatibility:Built-in OPC UA client,supports real-time data interaction with maxDNA system

I/O extension:

Analog interface:32-channel 16-bit ADC(±10V/4-20mA),sampling rate 10kHz

Digital interface:16-channel DI(24VDC)+16-channel DO(24VDC/1A)

2.Industrial-grade reliability design

Anti-interference ability:

Electromagnetic compatibility:complies with IEC 61000-4-2/-4-5 standard,with±25kV resistance

Signal isolation:The isolation voltage of analog channel is≥4kV,and the isolation voltage of digital channel is≥2.5kV

Environmental adaptability:

Wide temperature operation:-30°C to 70°C(operation)/-40°C to 85°C(storage)

Protection level:IP65(dust-proof and waterproof),suitable for outdoor/humid environments

3.Industry application adaptability

Special module extensions:

Safety control:can integrate SIL 2 certified safety module(need to external F3NC32-0N locator)

Energy management:Supports power factor compensation(PFC)algorithm,suitable for power system optimization

Technical Specifications:METSO BOU84 A413154

Parameters Specification Description

Processor Dual-core ARM Cortex-R5F,main frequency 800MHz

Memory 512MB DDR4+4GB SSD

Communication interface 2×EtherCAT(RJ45)+1×Profinet(RJ45)+1×RS-485(Modbus RTU)

I/O channel 32-point analog quantity(±10V/4-20mA)+32-point digital quantity(DI/DO)

Operating temperature-30℃to 70℃

Protection level IP65(standard configuration)

Core Values​​and Performance Highlights

1.High-precision analog quantity acquisition

Technical breakthrough:16-bit ADC resolution+anti-aliasing filter,ensuring±0.1%accuracy,suitable for steam turbine vibration monitoring and other scenarios

2.Dynamic environment adaptability

Scenario adaptation:100%operational reliability is maintained under high temperature environment of 70°C,suitable for thermal power plants,chemical equipment,etc.

Respond to challenges and create value

1.The traditional analog module has insufficient accuracy

Technical breakthrough:Eliminate the impact of ambient temperature on measurement through adaptive temperature compensation algorithm

2.Communication delay in complex systems

Scenario case:After a large power plant adopts BOU84 A413154,the analog data transmission delay is reduced to 1ms
