描述
产品简要说明
Metso D200175是一款高性能工业自动化模拟输入电子模块，核心功能包括：
多通道信号采集：支持电压、电流、温度、压力等模拟信号的高精度转换
灵活通信协议：兼容Modbus、EtherCAT、RS-485等工业总线协议
工业级防护：IP67防护等级，耐受-40°C至70°C环境
智能信号处理：内置滤波、线性化校正及数据记录功能
产品详细说明
1.技术架构与核心功能
信号输入特性：
通道配置：最多支持16路独立模拟输入通道（可扩展至32通道）
信号类型：
电压信号：0-10V、±5V、±10V
电流信号：4-20mA、0-20mA
温度信号：PT100/PT1000热电阻、热电偶（Type K/J/T）
压力信号：0-100bar范围可编程
精度等级：±0.1%满量程（FS）+2字节（24位ADC）
数据处理能力：
采样率：最高100kHz可配置采样频率
滤波算法：支持数字滤波（低通/高通）及抗混叠滤波
线性化校正：通过软件补偿非线性传感器输出（如压力变送器）
通信架构：
协议兼容性：Modbus TCP/IP、EtherCAT、Profibus DP、RS-485
网络接口：双千兆以太网端口（支持冗余配置）
数据存储：内置16GB固态存储，支持历史数据记录（最长30天）
2.工业环境适配性
极端温度管理：
热补偿机制：通过温度传感器实时校准信号漂移（-40°C至70°C）
散热设计：采用被动散热+导热硅胶贴片，70°C环境下功耗降低15%
抗干扰能力：
电磁兼容：符合IEC 61000-6-4标准（抗干扰等级≥90dB）
电气隔离：各通道间隔离电压≥2500V（耐压测试）
Product brief description
Metso D200175 is a high-performance industrial automation analog input electronic module with core functions including:
Multi-channel signal acquisition:supports high-precision conversion of analog signals such as voltage,current,temperature,and pressure.
Flexible communication protocol:compatible with industrial bus protocols such as Modbus,EtherCAT,RS-485,etc.
Industrial protection:IP67 protection rating,withstand-40°C to 70°C environment
Intelligent signal processing:built-in filtering,linear correction and data recording functions
Product details
1.Technical architecture and core functions
Signal input characteristics:
Channel configuration:Supports up to 16 independent analog input channels(scalable to 32 channels)
Signal type:
Voltage signal:0-10V,±5V,±10V
Current signal:4-20mA,0-20mA
Temperature signal:PT100/PT1000 Thermal Resistance,Thermocouple(Type K/J/T)
Pressure signal:0-100bar range programmable
Accuracy level:±0.1%full scale(FS)+2 bytes(24-bit ADC)
Data processing capability:
Sampling rate:up to 100kHz configurable sampling frequency
Filtering algorithm:supports digital filtering(low-pass/high-pass)and anti-aliasing filtering
Linearization correction:Compensate nonlinear sensor outputs(such as pressure transmitters)through software
Communication architecture:
Protocol compatibility:Modbus TCP/IP,EtherCAT,Profibus DP,RS-485
Network interface:Dual Gigabit Ethernet port(supports redundant configuration)
Data storage:Built-in 16GB solid state storage,supports historical data recording(up to 30 days)
2.Industrial environment adaptability
Extreme temperature management:
Thermal compensation mechanism:real-time calibration signal drift through temperature sensor(-40°C to 70°C)
Heat dissipation design:using passive heat dissipation+thermally conductive silicone patch,reducing power consumption by 15%in 70°C environment
Anti-interference ability:
Electromagnetic compatibility:complies with IEC 61000-6-4 standard(anti-interference level≥90dB)
Electrical isolation:The isolation voltage between each channel is≥2500V(withstanding voltage test)
