描述
一、产品定位
所属类别：
D200175可能为破碎机耐磨衬板（如圆锥破碎机动锥衬板、颚式破碎机颚板）、振动筛筛网或输送带托辊，具体需结合设备型号（如美卓Nordberg®GP系列圆锥破碎机、HP系列颚式破碎机）进一步确认。
设计目标：
抗磨损：采用高硬度合金材料（如高铬铸铁、硬质合金），适应铁矿石、铜矿石等硬岩破碎。
抗冲击：通过加厚设计、缓冲结构或弹性材料，承受大块物料冲击，减少断裂风险。
兼容性：严格匹配美卓原厂设备尺寸和安装接口，支持直接替换，无需改装。
二、技术参数（示例）
若D200175为圆锥破碎机动锥衬板，典型参数可能如下：
参数类别详细规格
材质高铬铸铁（Cr26-28%），硬度HRC≥58，抗冲击值≥5J/cm²
尺寸根据设备型号定制（如直径1200mm，高度350mm，重量约1.8吨）
表面处理激光熔覆（LC）或超音速火焰喷涂（HVOF），形成WC-Co硬质合金涂层，厚度0.2-0.4mm
适用工况进料粒度≤300mm，排料粒度6-25mm，处理能力300-600吨/小时
使用寿命在硬岩工况（如花岗岩）中可达5000-7000小时
三、典型应用场景
1.矿山破碎系统
圆锥破碎机：
D200175作为动锥衬板或定锥衬板，与传统锰钢衬板相比，耐磨性提升30%-50%，减少停机更换频率，适用于金矿、铁矿的中细碎。
分层破碎设计：上段粗碎、下段细碎，提高能量利用率，降低能耗10%-15%。
颚式破碎机：
若为颚板，采用曲面破碎腔，增加物料破碎次数，提高产品粒度均匀性，适用于石灰石、煤炭的粗碎。
2.筛分设备
振动筛筛网：
若D200175为聚氨酯筛网，具有高弹性、耐油性，防止湿料堵塞，筛分效率≥90%，适用于砂石、尾矿的分级。
3.输送系统
托辊或滚筒：
若为输送带托辊，采用迷宫密封设计，防护等级IP67，防止粉尘和水侵入，使用寿命≥50,000小时，减少皮带跑偏风险。
1.Product Positioning
Category:
D200175 may be a wear-resistant lining of a crusher(such as a cone lining of a cone crusher,a jaw plate of a jaw crusher),a vibrating screen or a conveyor belt roller.The specific model needs to be further confirmed in combination with the equipment model(such as Metso Nordberg®GP series cone crusher,HP series jaw crusher).
Design goal:
Wear resistance:Use high-hardness alloy materials(such as high-chromium cast iron,cemented carbide)to adapt to the crushing of hard rocks such as iron ore and copper ore.
Impact resistance:Through thickened design,buffer structure or elastic material,it can withstand the impact of large pieces of material and reduce the risk of breakage.
Compatibility:Strictly match the size and installation interface of Metso’s original equipment,support direct replacement without modification.
2.Technical parameters(example)
If D200175 is a cone crusher mobile cone liner,the typical parameters may be as follows:
Parameter category Detailed specifications
Material High chromium cast iron(Cr26-28%),hardness HRC≥58,impact resistance≥5J/cm²
Size Customized according to the equipment model(such as diameter 1200mm,height 350mm,weight about 1.8 tons)
Surface treatment Laser cladding(LC)or high velocity flame spraying(HVOF),forming WC-Co hard alloy coating,thickness 0.2-0.4mm
Applicable working conditions Feed particle size≤300mm,discharge particle size 6-25mm,processing capacity 300-600 tons/hour
Service life In hard rock conditions(such as granite)can reach 5000-7000 hours
3.Typical application scenarios
1.Mining crushing system
Cone crusher:
D200175 as Compared with the traditional manganese steel liner,the wear resistance of the movable cone liner or the fixed cone liner is improved by 30%-50%,which reduces the frequency of shutdown and replacement,and is suitable for medium and fine crushing of gold and iron ores.
Layered crushing design:upper coarse crushing and lower fine crushing improves energy utilization and reduces energy consumption by 10%-15%.
Jaw crusher:
If it is a jaw plate,a curved crushing chamber is used to increase the number of material crushing times and improve the uniformity of product particle size.It is suitable for coarse crushing of limestone and coal.
2.Screening equipment
Vibrating screen mesh:
If D200175 is a polyurethane screen mesh,it has high elasticity and oil resistance,prevents wet material clogging,and the screening efficiency is≥90%.It is suitable for the classification of sand and gravel and tailings.
3.Conveying system
Rollers or rollers:
If it is a conveyor belt roller,it adopts a labyrinth seal design with a protection level of IP67 to prevent dust and water intrusion,with a service life of≥50,000 hours,reducing the risk of belt deviation.
