描述
MITSUBISHI A1S61PN是三菱电机（Mitsubishi Electric）推出的一款电源模块，属于Melsec A系列，主要为三菱ANS系列可编程控制器提供稳定的直流电源。以下是其产品详情：
技术参数
输入电压：AC 100-240V（-15%至+10%）
输入频率：50/60Hz±5%
输入电压畸变率：5%以内
输入最大视在功率：105VA
突入电流：20A 8ms以内
额定输出电流：DC 5V/5A
过电流保护：DC 5V时为5.5A以上
过电压保护：DC 5V时为5.5-6.5V
效率：65%以上
允许瞬停时间：20ms以内
耐电压：输入/LG一括与输出/FG一括间AC 2300V/1min（标高0-2000m）
绝缘电阻：输入/LG一括与输出/FG一括间，用DC 500V绝缘电阻计测量为10MΩ以上
物理参数
外形尺寸：高130mm×宽55mm×深93.6mm
重量：0.60kg
其他特性
电源显示：具备LED电源状态指示灯。
外部配线连接方式：采用螺丝端子台（M3.5螺丝）。
符合标准：符合CE（EMC）、CE（LVD）、KC、LR、NK等标准。
适用底座单元：可安装在A1S3□B、A1S6□B、A1S3□HB、A1S3□HB EU、QA1S3□B、QA1S6□B等底座单元的电源插槽中。
The MITSUBISHI A1S61PN is a power supply module launched by Mitsubishi Electric.It belongs to the Melsec A series and is mainly used to provide stable DC power for Mitsubishi ANS series programmable controllers.The following are product details:
Technical Parameters
Input Voltage:AC 100-240V(-15%to+10%)
Input Frequency:50/60Hz±5%
Input Voltage Distortion:Within 5%
Maximum Input Apparent Power:105VA
Inrush Current:20A within 8ms
Rated Output Current:DC 5V/5A
Overcurrent Protection:5.5A or higher at DC 5V
Overvoltage Protection:5.5-6.5V at DC 5V
Efficiency:65%or higher
Permitted Momentary Power Interruption Duration:Within 20ms
Withstand Voltage:AC 2300V/1min between input/LG terminal block and output/FG terminal block(altitude 0-2000m)
Insulation Resistance:10MΩbetween input/LG terminal block and output/FG terminal block,measured with a DC 500V insulation resistance meter Above
Physical Parameters
Dimensions:Height 130mm×Width 55mm×Depth 93.6mm
Weight:0.60kg
Other Features
Power Indicator:LED power status indicator.
External Wiring:Screw terminal block(M3.5 screws).
Standards:Compliant with CE(EMC),CE(LVD),KC,LR,and NK standards.
Applicable Base Units:Compatible with the power supply slot of base units such as the A1S3□B,A1S6□B,A1S3□HB,A1S3□HB EU,QA1S3□B,and QA1S6□B.
