描述
三菱A1S68DAV是三菱电机推出的高性能模拟量输出模块，适用于工业自动化控制领域。以下是其核心功能、技术参数及应用特点的综合解析：
一、核心功能
数字模拟转换
-将数字信号（如PLC输出的数字指令）转换为模拟信号（电压或电流），支持工业设备的精确控制（如电机调速、温度调节）。
-支持8通道独立输出，可灵活配置电压（-5V～5V/10V～10V）或电流（4～20mA）信号类型。
高精度与稳定性
-转换精度高达12位，分辨率0.01%，满足高精度工业控制需求；
-长期可靠性设计，适应严苛工业环境（如高温、振动）。
安全保护功能
-输出短路保护：自动切断过载电流，防止模块损坏；
-过压/过流检测：实时监测输出状态，触发报警或断开负载。
二、技术参数
电气特性
-输入电源：直流24 V±10%，功耗≤0.65 A；
-输出特性：
-电压范围：-5V～5V/10V～10V；
-电流范围：4～20mA；
-最大负载能力：电压输出时≤200Ω，电流输出时≤500Ω。
转换性能
-转换速率：4 ms/8通道，单通道响应时间≤0.5 ms；
-线性度：±0.01%FSR（满量程误差）；
-温漂：≤0.005%FSR/℃。
通信与接口
-支持RS-485通信协议，兼容三菱PLC系统；
-输入输出点占用：32点（PLC资源分配）。
三、应用模式与扩展功能
STOP状态控制
-支持“HOLD”模式：PLC停止时保持当前模拟输出值；
-支持“CLR”模式：PLC停止时强制输出归零。
D/A转换执行设置
-可配置特定条件下禁止D/A转换（如故障时），避免异常输出影响设备。
扩展兼容性
-支持三菱A系列PLC（如A2ASCPU、QnASCPU）；
-可与定位模块、温度控制模块等协同工作，构建复杂控制系统。
四、物理特性
尺寸：130 mm×34.5 mm×93.6 mm（高×宽×深）；
重量：0.28 kg；
防护等级：IP20（非防尘防溅设计）。
Mitsubishi A1S68DAV is a high-performance analog output module launched by Mitsubishi Electric,suitable for the field of industrial automation control.The following is a comprehensive analysis of its core functions,technical parameters and application characteristics:
1.Core functions
Digital-to-analog conversion
-Convert digital signals(such as digital instructions output by PLC)into analog signals(voltage or current),supporting precise control of industrial equipment(such as motor speed regulation,temperature regulation).
-Support 8-channel independent output,and can flexibly configure voltage(-5V~5V/10V~10V)or current(4~20mA)signal types.
High precision and stability
-Conversion accuracy is up to 12 bits,with a resolution of 0.01%,meeting the needs of high-precision industrial control;
-Long-term reliability design,adapting to harsh industrial environments(such as high temperature,vibration).
Safety protection function
-Output short-circuit protection:automatically cut off overload current to prevent module damage;
-Overvoltage/overcurrent detection:real-time monitoring of output status,triggering alarms or disconnecting loads.
2.Technical parameters
Electrical characteristics
-Input power:DC 24 V±10%,power consumption≤0.65 A;
-Output characteristics:
-Voltage range:-5V~5V/10V~10V;
-Current range:4~20mA;
-Maximum load capacity:≤200Ωfor voltage output,≤500Ωfor current output.
Conversion performance
-Conversion rate:4 ms/8 channels,single channel response time≤0.5 ms;
-Linearity:±0.01%FSR(full scale error);
-Temperature drift:≤0.005%FSR/℃.
Communication and interface
-Support RS-485 communication protocol,compatible with Mitsubishi PLC system;
-Input and output point occupancy:32 points(PLC resource allocation).
3.Application mode and extended functions
STOP state control
-Support”HOLD”mode:keep the current analog output value when PLC stops;
-Support”CLR”mode:force the output to zero when PLC stops.
D/A conversion execution setting
-It can be configured to prohibit D/A conversion under specific conditions(such as failure)to avoid abnormal output affecting the device.
Extended compatibility
-Support Mitsubishi A series PLC(such as A2ASCPU,QnASCPU);
-Can work with positioning modules,temperature control modules,etc.to build complex control systems.
4.Physical characteristics
Dimensions:130 mm×34.5 mm×93.6 mm(height×width×depth);
Weight:0.28 kg;
Protection level:IP20(non-dust and splashproof design).
