描述
MODICON AS-BADU-204是施耐德电气Modicon系列的模拟量输入模块。主要用于将温度、压力、流量等模拟信号转换为数字信号，以便PLC进行处理和控制。具体详情如下：
产品参数：
通道数：4个输入通道。
输入信号类型：支持电压、电流信号，可连接PT100、PT1000等温度传感器。
分辨率：12位或更高，精度可达±0.1%FS。
采样率：可配置。
隔离电压：1500Vrms。
工作温度范围：-20℃至60℃。
防护等级：IP66。
工作电压：24V DC。
最大输出电流：2A。
通信协议：支持Modbus RTU、RS-485等。
产品特点：
高精度：采用高精度A/D转换器，确保数据测量的准确性。
多通道设计：支持同时采集多个信号，提高系统的灵活性。
隔离保护：输入与输出通道隔离，增强抗干扰能力。
模块化设计：便于安装和维护。
灵活配置：通过软件灵活配置输入范围和滤波方式，适应不同应用需求。
应用领域：广泛应用于石油化工、电力、冶金、工厂自动化、楼宇自动化等领域，可用于工业过程中的温度、压力、流量等参数的监测和控制，也可用于能源管理系统中能源消耗的监测和优化等场景
The MODICON AS-BADU-204 is an analog input module from Schneider Electric’s Modicon series.It is primarily used to convert analog signals such as temperature,pressure,and flow into digital signals for PLC processing and control.Specific details are as follows:
Product Parameters:
Number of Channels:4 input channels.
Input Signal Type:Supports voltage and current signals and can connect to temperature sensors such as PT100 and PT1000.
Resolution:12-bit or higher,with an accuracy of±0.1%FS.
Sampling Rate:Configurable.
Isolation Voltage:1500 Vrms.
Operating Temperature Range:-20°C to 60°C.
Protection Rating:IP66.
Operating Voltage:24V DC.
Maximum Output Current:2A.
Communication Protocols:Supports Modbus RTU,RS-485,and others.
Features:
High Accuracy:Utilizes a high-precision A/D converter to ensure accurate data measurement.Multi-channel design:Supports simultaneous acquisition of multiple signals,enhancing system flexibility.
Isolation protection:Isolates input and output channels for enhanced anti-interference capabilities.
Modular design:Eases installation and maintenance.
Flexible configuration:Software-configurable input range and filtering methods adapt to diverse application requirements.
Applications:Widely used in the petrochemical,power,metallurgy,factory automation,building automation,and other fields.It can be used to monitor and control parameters such as temperature,pressure,and flow in industrial processes,as well as monitor and optimize energy consumption in energy management systems.
