描述
产品概述
MOOG G403-552A是穆格（MOOG）旗下的工业编码器，采用绝对式编码技术，专为高精度、高可靠性场景设计，适用于机械自动化、机器人、数控机床等工业领域。其核心特点包括高脉冲率、重载结构和抗干扰能力。
核心功能与技术参数
1.核心性能
编码方式：
绝对式编码：无需通电记忆位置，断电后数据不丢失。
接触式读出：通过物理触点传输信号，确保稳定性和耐用性。
脉冲率：
最高脉冲率可达16,348脉冲/转（可能为每转脉冲数或每圈分辨率），支持高精度位置检测。
工作原理：
脉冲盘与扫描器分离设计，提升抗振动和冲击能力。
2.硬件设计
安装结构：
支持法兰安装和底脚安装，适配多种机械布局。
防护性能：
重载设计：通过冲击测试，适用于严苛工业环境。
尺寸与重量：
外形尺寸：25-60 mm（具体因型号而异）；
重量：3-8 kg。
3.电气参数
电压范围：
6-30 V（兼容宽电压输入）。
输出接口：
差动线路输出：抵抗瞬时短路，确保信号传输稳定性。
功率：
根据具体型号确定，典型值未明确标注。
4.环境适应性
适用范围：
无特殊限制，适用于常规工业环境。
环境条件：
温度、湿度等参数未明确，但基于工业编码器设计，推测具备一定的耐温（如-20°C至+60°C）和防尘能力。
关键特性
高可靠性：
重载结构和分离式脉冲盘设计，减少因振动或冲击导致的故障。
抗干扰能力：
差动输出线路有效抑制电磁干扰，确保信号完整性。
模块化兼容：
可与穆格其他工业传感器、电机等设备集成，适配自动化系统需求。.
.
Product Overview
MOOG G403-552A is an industrial encoder under MOOG.It adopts absolute coding technology and is designed for high-precision and high-reliability scenarios.It is suitable for industrial fields such as mechanical automation,robots,and CNC machine tools.Its core features include high pulse rate,heavy-load structure and anti-interference ability.
Core functions and technical parameters
1.Core Performance
Coding method:
Absolute encoding:no need to power on to remember the position,and data will not be lost after power off.
Contact Reading:Transmit signals through physical contacts to ensure stability and durability.
Pulse Rate:
The maximum pulse rate can reach 16,348 pulses/rpm(maybe pulse count per revolution or resolution per turn),and supports high-precision position detection.
How it works:
The pulse disc is separated from the scanner to improve vibration and shock resistance.
2.Hardware design
Installation structure:
Supports flange installation and foot installation,and is suitable for a variety of mechanical layouts.
Protection performance:
Heavy-load design:Passes impact testing,suitable for harsh industrial environments.
Size and Weight:
Dimensions:25-60 mm(specifically vary by model);
Weight:3-8 kg.
3.Electrical parameters
Voltage range:
6-30 V(compatible with wide voltage input).
Output interface:
Differential line output:Resist instantaneous short circuit to ensure signal transmission stability.
power:
Determine based on the specific model,and the typical valuesare not clearly marked.
4.Environmental adaptability
Scope of application:
No special restrictions,applicable to conventional industrial environments.
Environmental conditions:
The temperature,humidity and other parameters are not clear,but based on the design of the industrial encoder,it is estimated that it has certain temperature resistance(such as-20°C to+60°C)and dust resistance.
Key Features
High reliability:
Heavy-load structure and split-type pulse disc design to reduce faults caused by vibration or shock.
Anti-interference ability:
The differential output line effectively suppresses electromagnetic interference and ensures signal integrity.
Modular compatibility:
It can be integrated with other industrial sensors,motors and other equipment to adapt to automation system requirements.
