描述
1.产品概述
RSG2PMC和RSG2PMCF-NK2是全千兆工业以太网交换机，采用无风扇设计与金属外壳，具备IP40/IP67防护等级，可适应-40℃至+75℃工作温度。产品支持IEEE 802.3af/at PoE++供电，可为IP摄像头、无线接入点、工业传感器等设备供电；内置工业级元器件，通过IEC 61850、EN 50121-4等标准认证，满足电力、轨道交通等行业的严苛要求。
核心定位
应用场景：
制造业：工厂车间内的PLC、机器人控制器、HMI的高速通信，支持实时控制与数据采集。
能源行业：风电场、光伏电站的风机监控、逆变器通信，适应户外恶劣环境。
交通领域：地铁、高铁的车载网络、站台设备联网，保障高可靠性与低延迟。
物流仓储：自动化立体仓库的AGV调度、货架传感器的无线/有线混合组网。
技术优势：
高可靠性：支持RSTP/MSTP冗余协议，网络自愈时间<20ms，避免单点故障导致中断。
强抗干扰：EMI/EMC防护等级达Class A，适应强电磁环境（如变电站、电焊车间）。
灵活供电：PoE++（802.3at）可为8台终端设备供电，简化布线与电源管理。
统一管理：支持SNMP、Web、CLI等管理方式，可与Motorola其他工业设备集成管理。
2.技术规格与性能参数
2.1基础参数
参数RSG2PMC RSG2PMCF-NK2
型号RSG2PMC RSG2PMCF-NK2
制造商Motorola Solutions（Zebra）Motorola Solutions（Zebra）
产品类型全千兆工业以太网交换机全千兆工业以太网交换机（增强型）
端口配置-8个10/100/1000Mbps RJ45
-2个1G SFP光口-12个10/100/1000Mbps RJ45
-4个1G SFP光口
PoE供电支持802.3af/at（每端口30W），最大120W总功率支持802.3af/at（每端口30W），最大240W总功率
处理器Marvell ARM Cortex-A9，500MHz Marvell ARM Cortex-A9，800MHz
内存256MB DDR3 512MB DDR3
闪存128MB NAND Flash 256MB NAND Flash
1.Product Overview
RSG2PMC and RSG2PMCF-NK2 are full Gigabit industrial Ethernet switches with fanless design and metal casing,IP40/IP67 protection level,and can adapt to-40℃to+75℃operating temperature.The products support IEEE 802.3af/at PoE++power supply,which can power IP cameras,wireless access points,industrial sensors and other devices;built-in industrial-grade components,certified by IEC 61850,EN 50121-4 and other standards,meet the stringent requirements of industries such as power and rail transit.
Core Positioning
Application Scenarios:
Manufacturing:high-speed communication of PLC,robot controller,and HMI in factory workshops,supporting real-time control and data acquisition.
Energy Industry:wind turbine monitoring and inverter communication in wind farms and photovoltaic power stations,adapting to harsh outdoor environments.
Transportation:on-board networks and platform equipment networking of subways and high-speed railways to ensure high reliability and low latency.
Logistics warehousing:AGV scheduling of automated warehouses,wireless/wired hybrid networking of shelf sensors.
Technical advantages:
High reliability:Supports RSTP/MSTP redundancy protocols,network self-healing time<20ms,avoiding interruptions caused by single point failures.
Strong anti-interference:EMI/EMC protection level reaches Class A,adapting to strong electromagnetic environments(such as substations and welding workshops).
Flexible power supply:PoE++(802.3at)can power 8 terminal devices,simplifying wiring and power management.
Unified management:Supports SNMP,Web,CLI and other management methods,and can be integrated with other Motorola industrial equipment.
2.Technical specifications and performance parameters
2.1 Basic parameters
Parameters RSG2PMC RSG2PMCF-NK2
Model RSG2PMC RSG2PMCF-NK2
Manufacturer Motorola Solutions(Zebra)Motorola Solutions(Zebra)
Product type Full Gigabit Industrial Ethernet Switch Full Gigabit Industrial Ethernet Switch(Enhanced)
Port configuration-8 10/100/1000Mbps RJ45
-2 1G SFP optical ports-12 10/100/1000Mbps RJ45
-4 1G SFP optical ports
PoE power supply Support 802.3af/at(30W per port),maximum 120W total power Support 802.3af/at(30W per port),maximum 240W total power
Processor Marvell ARM Cortex-A9,500MHz Marvell ARM Cortex-A9,800MHz
Memory 256MB DDR3 512MB DDR3
Flash 128MB NAND Flash 256MB NAND Flash
