描述
MR-S11-200-Z37是Moxa（摩莎）推出的一款工业级千兆以太网交换机，属于EDS（Enterprise Digital Switch）系列，专为严苛工业环境设计，具备高可靠性、强抗干扰能力、灵活扩展性，广泛应用于轨道交通、电力、智能制造、智慧城市等领域的实时数据通信与设备联网。
1.产品定位与核心优势
1.1应用场景
轨道交通：地铁、高铁的车载网络、站台设备联网，支持振动、宽温、电磁干扰环境。
电力行业：变电站、风电场的监控系统、保护装置通信，符合IEC 61850-3标准。
智能制造：工厂车间的PLC、机器人、传感器高速互联，满足实时控制与数据采集需求。
智慧城市：交通信号灯、环境监测设备的户外联网，适应防水、防尘、耐腐蚀要求。
1.2技术亮点
工业级设计：
无风扇散热，IP40防护等级，-40℃至+75℃宽温工作。
金属外壳（铝合金），抗振动/冲击（符合IEC 60068-2-6/27）。
高可靠性网络：
支持RSTP/MSTP/ERPS冗余协议，网络自愈时间<20ms。
双电源冗余输入（12-48V DC），避免电源故障导致中断。
灵活扩展性：
8个千兆电口+2个千兆光口，支持光纤长距离传输（可达80km）。
可选PoE++供电（需确认具体型号），为IP摄像头、无线AP供电。
2.技术规格与详细参数
2.1基础参数
参数规格
型号MR-S11-200-Z37
制造商Moxa（摩莎）
系列EDS（Enterprise Digital Switch）
端口配置-8个10/100/1000Mbps RJ45电口
-2个1G SFP光口
PoE供电非标准PoE型号（部分型号支持802.3af/at，需确认具体配置）
处理器Marvell ARM Cortex-A9，600MHz
内存256MB DDR3
闪存128MB NAND Flash
尺寸（W×H×D）138×44×105 mm（不含安装件）
重量约650g
MR-S11-200-Z37 is an industrial-grade Gigabit Ethernet switch launched by Moxa.It belongs to the EDS(Enterprise Digital Switch)series and is designed for harsh industrial environments.It has high reliability,strong anti-interference ability,and flexible scalability.It is widely used in real-time data communication and equipment networking in rail transit,power,smart manufacturing,smart cities and other fields.
1.Product positioning and core advantages
1.1 Application scenarios
Rail transit:on-board network and platform equipment networking of subways and high-speed railways,supporting vibration,wide temperature,and electromagnetic interference environments.
Power industry:monitoring systems and protection device communications of substations and wind farms,in accordance with IEC 61850-3 standards.
Smart manufacturing:high-speed interconnection of PLCs,robots,and sensors in factory workshops to meet real-time control and data acquisition requirements.
Smart city:outdoor networking of traffic lights and environmental monitoring equipment to meet waterproof,dustproof,and corrosion-resistant requirements.
1.2 Technical highlights
Industrial-grade design:
Fanless cooling,IP40 protection level,-40℃to+75℃wide operating temperature.
Metal casing(aluminum alloy),vibration/shock resistance(compliant with IEC 60068-2-6/27).
High-reliability network:
Supports RSTP/MSTP/ERPS redundancy protocols,network self-healing time<20ms.
Dual power supply redundant input(12-48V DC)to avoid interruption caused by power failure.
Flexible scalability:
8 Gigabit electrical ports+2 Gigabit optical ports,supporting long-distance optical fiber transmission(up to 80km).
Optional PoE++power supply(need to confirm the specific model)to power IP cameras and wireless APs.
2.Technical specifications and detailed parameters
2.1 Basic parameters
Parameters Specifications
Model MR-S11-200-Z37
Manufacturer Moxa
Series EDS(Enterprise Digital Switch)
Port configuration-8 10/100/1000Mbps RJ45 electrical ports
-2 1G SFP optical ports
PoE power supply Non-standard PoE model(some models support 802.3af/at,need to confirm the specific configuration)
Processor Marvell ARM Cortex-A9,600MHz
Memory 256MB DDR3
Flash memory 128MB NAND Flash
Dimensions(W×H×D)138×44×105 mm(excluding mounting parts)
Weight About 650g
