Novellus 02-130617-00N C3

2.高可靠性设计

技术实现:

输入通道浪涌抑制(支持8kV ESD防护)

输出通道过载保护(支持短路熔断机制)

3.智能诊断功能

故障处理:

实时监测通道异常状态(如断线、短路)

事件日志存储(容量512KB)

应对挑战,创造价值

1.复杂信号处理

解决方案:

支持脉冲信号频率测量(最高10kHz)

软硬件滤波结合(降低噪声干扰)

描述

产品简要说明

Novellus 02-130617-00N C3是一款面向工业自动化领域的数字输入输出模块,核心特性包括:

多通道控制:支持8通道隔离数字输入与8通道继电器输出

工业网络兼容:集成Modbus Plus通信协议

环境适应性:IP65防护等级,宽温工作范围

产品详细说明

1.硬件架构设计

核心处理器:

基于32位微控制器(如STM32F4系列)

内存配置:128KB Flash+64KB RAM

通信接口:

Modbus Plus主从站协议(支持9.6kbps至19.2kbps)

光耦隔离I/O接口(耐压3kV)

2.输入输出特性

输入通道:

8路隔离数字输入(兼容24V DC/AC信号)

响应时间≤5ms

输出通道:

8路继电器输出(触点容量2A/250V AC)

状态反馈监测功能

3.工业环境适配

温度管理:

工作温度:-30℃至+70℃

温度漂移补偿算法(误差<±0.5%)

抗干扰设计:

EMI抗扰等级Class B

电源滤波电路(支持50Hz/60Hz电网干扰抑制)

技术规格:Novellus 02-130617-00N C3

参数项规格描述

通道配置8DI+8DO

通信协议Modbus Plus

防护等级IP65

电源输入24V DC±10%

核心价值与性能亮点

1.多协议兼容性

应用场景:

与施耐德Quantum系列PLC(如140DDO84300模块)无缝集成

在离散制造业中实现设备状态监测与控制指令下发

2.高可靠性设计

技术实现:

输入通道浪涌抑制(支持8kV ESD防护)

输出通道过载保护(支持短路熔断机制)

3.智能诊断功能

故障处理:

实时监测通道异常状态(如断线、短路)

事件日志存储(容量512KB)

应对挑战,创造价值

1.复杂信号处理

解决方案:

支持脉冲信号频率测量(最高10kHz)

软硬件滤波结合(降低噪声干扰)

2.分布式系统扩展

技术实现:

支持最多16个模块级联(通过Modbus Plus总线)

主站响应时间≤20ms

Product brief description

Novelus 02-130617-00N C3 is a digital input and output module for the field of industrial automation,with core features including:

Multi-channel control:Supports 8-channel isolated digital input and 8-channel relay output

Industrial network compatibility:Integrated Modbus Plus communication protocol

Environmental adaptability:IP65 protection level,wide temperature working range

Product details

1.Hardware architecture design

Core processor:

Based on 32-bit microcontrollers(such as STM32F4 series)

Memory configuration:128KB Flash+64KB RAM

Communication interface:

Modbus Plus master and slave protocol(supports 9.6kbps to 19.2kbps)

Optocoupler isolation I/O interface(with 3kV voltage)

2.Input and output characteristics

Input channel:

8-channel isolated digital inputs(compatible with 24V DC/AC signals)

Response time≤5ms

Output channel:

8-channel relay output(contact capacity 2A/250V AC)

Status feedback monitoring function

3.Industrial environment adaptation

Temperature management:

Operating temperature:-30℃to+70℃

Temperature drift compensation algorithm(Error<±0.5%)

Anti-interference design:

EMI immunity level Class B

Power supply filter circuit(supports 50Hz/60Hz grid interference suppression)

Technical Specifications:Novellus 02-130617-00N C3

Parameters Specification Description

Channel Configuration 8DI+8DO

Communication Protocol Modbus Plus

Protection level IP65

Power input 24V DC±10%

Core Values​​and Performance Highlights

1.Multi-protocol compatibility

Application scenarios:

Seamless integration with Schneider Quantum series PLCs(such as the 140DDO84300 module)

Implement equipment status monitoring and control instructions in discrete manufacturing

2.High reliability design

Technical implementation:

Input channel surge suppression(supports 8kV ESD protection)

Output channel overload protection(supports short-circuit fuse mechanism)

3.Intelligent diagnostic function

Troubleshooting:

Real-time monitoring of abnormal channel status(such as disconnection,short circuit)

Event log storage(capacity 512KB)

Respond to challenges and create value

1.Complex signal processing

Solution:

Support pulse signal frequency measurement(up to 10kHz)

Combination of software and hardware filtering(reduce noise interference)

2.Distributed system extension

Technical implementation:

Supports up to 16 module cascades(via Modbus Plus)

Main site response time≤20ms
