描述
OMRON C200H-ID217是欧姆龙推出的一款高密度数字输入模块，适用于C200H系列可编程控制器系统。以下是其产品详情：
输入通道：具备64个数字输入通道，分为2组，每组32个输入点（即2个公共端，每个公共端32个输入点）。
额定电压：额定输入电压为24V DC，工作输入电压范围是20.4V DC至26.4V DC，最小导通电压额定值为14.4V DC，最大关断电压额定值为5V DC。
输入阻抗：输入阻抗为5.6千欧。
电流消耗：内部电流消耗为5V DC时120mA。
响应时间：导通和关断响应时间最大均为1ms。
隔离特性：每组具有300V rms、II类工作隔离，具备2300V rms瞬态过电压保护功能。
工作温度：工作温度范围为0℃至55℃。
认证：通过CE、CSA、UL等认证。
机械特性：防护等级为IP30，外形尺寸约为10.4cm×7.8cm×8cm，重量约0.4kg。
接口类型：采用D-sub接口，方便与外部设备连接。
The OMRON C200H-ID217 is a high-density digital input module designed for use with the C200H series programmable controller system.Product details are as follows:
Input Channels:64 digital input channels,organized into two groups of 32 inputs each(i.e.,two common terminals,32 inputs per common terminal).
Rated Voltage:The rated input voltage is 24V DC,with an operating input voltage range of 20.4V DC to 26.4V DC.The minimum on-state voltage rating is 14.4V DC,and the maximum off-state voltage rating is 5V DC.
Input Impedance:5.6 kilohms.
Current Draw:Internal current draw is 120mA at 5V DC.
Response Time:Maximum on-and off-state response times are both 1ms.
Isolation:Each pair provides 300V rms Class II isolation,with 2300V rms transient overvoltage protection.
Operating Temperature:Operating temperature range is 0°C to 55°C.
Certification:CE,CSA,and UL certified.
Mechanical Characteristics:IP30 protection rating,dimensions approximately 10.4cm×7.8cm×8cm,weight approximately 0.4kg.
Interface:D-sub connector for easy connection to external devices.
