描述
OMRON C200HW-PA204S是欧姆龙C200HW系列的电源模块，主要为可编程控制器系统提供稳定电源。以下是其产品详情：
电源规格：电源电压为100-120VAC或200-240VAC，频率50/60Hz；工作电压范围是85-132VAC或170-264VAC。
输出特性：包含24VDC输出端子，可为PLC系统中的直流输入单元提供直流电源。
功率消耗：最大功耗为120VA。
电气隔离：绝缘电阻在AC外部与接地端子之间，以及所有报警输出端子与接地端子之间，在500VDC时最小为20MΩ。介电强度方面，AC外部与接地端子之间为2300VAC，50/60Hz，持续1分钟，漏电流最大10mA。
机械参数：单位重量约1.1磅（约0.5kg），安装的机架最大重量为6kg，可采用背板或机架安装方式。
工作环境：工作温度范围为0-55℃，工作湿度为10%-90%（无冷凝）。
通信特性：主机链接接口允许与PLC通信，其运行速度比外围总线慢。但当使用RS-422A/RS-485进行连接，特别是使用调制解调器或光适配器时，主机链接接口支持1:n连接和远程连接。
认证标准：符合UL、CSA、NK、Lloyd、EC指令和CE等标准，确保运行的安全性和可靠性。
The OMRON C200HW-PA204S is a power supply module from the OMRON C200HW series,primarily designed to provide stable power for programmable controller systems.The following are product details:
Power Supply Specifications:Power supply voltage is 100-120VAC or 200-240VAC,50/60Hz;operating voltage range is 85-132VAC or 170-264VAC.
Output Characteristics:Includes a 24VDC output terminal for providing DC power to DC input units in PLC systems.
Power Consumption:Maximum power consumption is 120VA.
Electrical Isolation:Insulation resistance is a minimum of 20MΩat 500VDC between the AC external terminal and ground,and between all alarm output terminals and ground.Dielectric strength is rated at 2300VAC,50/60Hz,for one minute between the AC external terminal and ground,with a maximum leakage current of 10mA.Mechanical Parameters:Unit weight is approximately 1.1 lb(approximately 0.5 kg),with a maximum rack weight of 6 kg.It can be mounted in either a backplane or rack configuration.
Operating Environment:Operating temperature range is 0-55°C,and operating humidity is 10%-90%(non-condensing).
Communication Characteristics:The host link interface allows communication with the PLC,operating at a slower speed than the peripheral bus.However,when connected via RS-422A/RS-485,especially when using a modem or optical adapter,the host link interface supports 1:n and remote connections.
Certifications:Complies with UL,CSA,NK,Lloyd’s,EC directives,and CE standards,ensuring operational safety and reliability.
