描述
PANASONIC MSD043A1XX是松下生产的一款交流伺服驱动器。以下是其产品详情：
基本信息
产品类型：交流伺服驱动器
系列：MSD系列
外形尺寸：180mm x 130mm x 70mm
安装方式：壁挂式
性能参数
额定功率：400W
额定电压：230VAC
额定电流：1.7A
速度范围：0-3000rpm
扭矩范围：0-1.8N·m
控制精度：±0.01%
响应速度：≤1ms
速度响应频率：3kHz
编码器分辨率：最高20位
通信接口：支持RS-232、RS-485、CAN等多种通信接口，部分型号还支持EtherCAT、Profinet等协议。
功能特点
全数字驱动架构：采用DSP+IPM（智能功率模块）设计，内置过压、过流、过热、欠压保护，延长设备寿命。
自适应滤波器：根据机械共振频率自动调整陷波滤波参数，抑制振动，提升加工表面质量。
一键式增益调整：通过驱动器面板或软件，快速完成系统增益优化，降低调试难度。
应用领域
制造业：用于控制机器人、数控机床、包装机械等设备。
印刷业：用于控制印刷机的纸张输送、张力控制和定位等。
半导体制造：用于控制晶圆搬运机、光刻机、清洗机等设备。
电子制造：用于控制贴片机、测试机、分拣机等设备。
The PANASONIC MSD043A1XX is an AC servo drive manufactured by Panasonic.The following are product details:
Basic Information
Product Type:AC Servo Drive
Series:MSD Series
Dimensions:180mm x 130mm x 70mm
Mounting Method:Wall-mounted
Performance Parameters
Rated Power:400W
Rated Voltage:230VAC
Rated Current:1.7A
SpeedRange:0-3000rpm
Torque Range:0-1.8N·m
Control Accuracy:±0.01%
Response Speed:≤1ms
SpeedResponse Frequency:3kHz
Encoder Resolution:Up to 20 bits
Communication Interface:Supports multiple communication interfaces including RS-232,RS-485,and CAN.Some models also support protocols such as EtherCAT and Profinet.
Features
Fully digital drive architecture:Utilizes a DSP+IPM(Intelligent Power Module)design with built-in overvoltage,overcurrent,overtemperature,and undervoltage protection to extend device life.Adaptive Filter:Automatically adjusts notch filter parameters based on mechanical resonance frequency,suppressing vibration and improving surface quality.
One-click Gain Adjustment:Quickly optimize system gain via the driver panel or software,simplifying debugging.
Applications
Manufacturing:Controls robots,CNC machine tools,packaging machinery,and other equipment.
Printing:Controls paper feed,tension control,and positioning in printing presses.
Semiconductor Manufacturing:Controls wafer handlers,photolithography machines,and cleaning machines.
Electronics Manufacturing:Controls placement machines,testers,and sorting machines.
