描述
一、产品命名规则解析
PIONEER MAGNETICS的型号通常包含关键参数信息，PM3398B-6-1-3-E 80026-172-24可拆解为：
PM3398B：基础型号，表示系列与版本。
6：输出电压为6VDC（或相关电压等级标识）。
1：输出电流或功率等级（需结合具体参数确认）。
3：封装类型或接口配置（如导轨安装、PCB焊接等）。
E：环境适应性标识（如扩展温度范围、防尘防水等）。
80026-172-24：可能为客户定制编号、批次号或认证标识，需结合具体文档确认。
二、核心电气参数
1.输入特性
输入电压范围：
交流（AC）：85VAC~264VAC（单相，47Hz~63Hz），支持全球电网兼容性。
直流（DC）：120VDC~370VDC（可选输入模式，适用于备用电源系统）。
输入电流：
满载时<8A（115VAC）/<4A（230VAC），降低线路损耗。
功率因数（PFC）：
内置主动式功率因数校正（APFC），典型值>0.98（满载），符合IEC 61000-3-2谐波标准，减少对电网的污染。
2.输出特性
输出电压：
标称值：6VDC（可能支持微调，需确认具体型号变体）。
负载调整率：<±0.5%（线性负载），<±1%（非线性负载），确保输出稳定性。
输出电流：
假设型号中“1”代表电流等级，可能为10A~30A（需参考具体数据手册）。
支持恒压（CV）/恒流（CC）模式自动切换，适应不同负载需求。
纹波与噪声：
<50mVp-p（20MHz带宽），满足低噪声敏感设备（如医疗仪器、音频设备）的供电要求。
动态响应：
负载突变（50%~100%）时，输出电压恢复时间<50μs，快速响应负载变化。
3.效率与散热
满载效率：
>92%（230VAC输入），>90%（115VAC输入），降低系统能耗与发热。
散热方式：
自然风冷（默认配置），支持强制风冷（可选风扇）以提升高温环境下的可靠性。
工作温度范围****：-40℃~+85℃（工业级宽温设计），适应极端环境。
降额曲线：
温度超过60℃时，输出功率按-2%/℃线性降额，确保长期稳定性。
三、保护功能与可靠性设计
1.多重保护机制
过压保护（OVP）：输出电压超过6.6V±1%时，自动关断输出并锁存，需手动复位或远程信号解锁。
过流保护（OCP）：输出电流超过额定值110%时，进入打嗝模式（Hiccup Mode），故障排除后自动恢复。
短路保护（SCP）：输出短路时，限流至<120%额定电流，短路移除后立即恢复供电。
过温保护（OTP）：内部温度超过110℃时，关闭电源以防止损坏，温度降至90℃后自动重启。
输入欠压/过压保护：输入电压低于80VAC或高于275VAC时，关闭电源并报警。
2.电磁兼容性（EMC）
传导干扰：符合EN 55032 Class A/B标准（根据配置可选），通过FCC Part 15B认证。
辐射干扰：满足CISPR 32 Class B要求，适用于室内/室外工业环境。
1.Analysis of product naming rules
PIONEER MAGNETICS models usually contain key parameter information.PM3398B-6-1-3-E 80026-172-24 can be disassembled into:
PM3398B:Basic model,indicating series and version.
6:Output voltage is 6VDC(or related voltage level identification).
1:Output current or power level(need to be confirmed in combination with specific parameters).
3:Package type or interface configuration(such as rail installation,PCB welding,etc.).
E:Environmental adaptability identification(such as extended temperature range,dust and water resistance,etc.).
80026-172-24:May be a customer-customized number,batch number or certification mark,which needs to be confirmed in combination with specific documents.
2.Core electrical parameters
1.Input characteristics
Input voltage range:
AC:85VAC~264VAC(single phase,47Hz~63Hz),supporting global power grid compatibility.
Direct current(DC):120VDC~370VDC(optional input mode,suitable for backup power supply system).
Input current:
<8A(115VAC)/<4A(230VAC)at full load,reducing line loss.
Power factor(PFC):
Built-in active power factor correction(APFC),typical value>0.98(full load),in line with IEC 61000-3-2 harmonic standard,reducing pollution to the power grid.
2.Output characteristics
Output voltage:
Nominal value:6VDC(may support fine-tuning,need to confirm the specific model variant).
Load adjustment rate:<±0.5%(linear load),<±1%(non-linear load),to ensure output stability.
Output current:
Assuming that”1″in the model represents the current level,it may be 10A~30A(please refer to the specific data sheet).
Supports automatic switching between constant voltage(CV)/constant current(CC)mode to adapt to different load requirements.
Ripple and noise:<50mVp-p(20MHz bandwidth),meeting the power supply requirements of low-noise sensitive equipment(such as medical instruments,audio equipment).Dynamic response:When the load changes suddenly(50%~100%),the output voltage recovery time is<50μs,which responds quickly to load changes.3.Efficiency and heat dissipation Full load efficiency:>92%(230VAC input),>90%(115VAC input),reducing system energy consumption and heat generation.Cooling method:Natural air cooling(default configuration),support forced air cooling(optional fan)to improve reliability in high temperature environment.Operating temperature range****:-40℃~+85℃(industrial-grade wide temperature design),adaptable to extreme environments.Derating curve:When the temperature exceeds 60℃,the output power is linearly derated by-2%/℃to ensure long-term stability.3.Protection function and reliability design
1.Multiple protection mechanisms
Overvoltage protection(OVP):When the output voltage exceeds 6.6V±1%,the output is automatically shut down and latched,and manual reset or remote signal unlocking is required.
Overcurrent protection(OCP):When the output current exceeds 110%of the rated value,it enters the hiccup mode and automatically recovers after the fault is eliminated.
Short circuit protection(SCP):When the output is short-circuited,the current is limited to<120%of the rated current,and the power supply is restored immediately after the short circuit is removed.
Overtemperature protection(OTP):When the internal temperature exceeds 110℃,the power supply is turned off to prevent damage,and it automatically restarts after the temperature drops to 90℃.
Input undervoltage/overvoltage protection:When the input voltage is lower than 80VAC or higher than 275VAC,the power supply is turned off and an alarm is issued.
2.Electromagnetic compatibility(EMC)
Conducted interference:Complies with EN 55032 Class A/B standards(optional according to configuration)and passed FCC Part 15B certification.
Radiated interference:Meets CISPR 32 Class B requirements,suitable for indoor/outdoor industrial environments.
