描述
1.产品定位与核心功能
PORT-789917是申克（SCHENCK Process GmbH）推出的工业通信接口模块，属于CONiQ®数字化称重系统的核心组件。其设计目标为多传感器数据整合与高速通信，支持称重传感器、振动传感器等设备的信号同步传输，适配智能制造与工业物联网（IIoT）场景，具备冗余通信与实时诊断功能。
2.关键技术参数推断
基于申克接口模块产品线特征（参考VKK 280x系列与CONiQ®技术框架）：
通信协议：
-支持EtherCAT、ProfiNet、Modbus TCP/IP（兼容主流PLC与SCADA系统）；
-可选OPC UA（适配云平台数据交互）。
通道容量：
-最多支持16路传感器输入（兼容模拟与数字信号）；
-通道隔离：光电隔离（抑制共模干扰≥150 Vrms）。
环境适应性：
-防护等级：IP67（防尘防水，适配户外机柜）；
-工作温度：-30°C至+85°C（宽温设计）。
3.典型应用场景
智能工厂集成
-多称重传感器组网（如料仓群实时监测）；
-振动与重量数据融合分析（预测设备失效风险）。
物流与仓储
-自动化立体仓库载荷监控（支持千兆以太网实时反馈）；
-AGV小车动态称重（与MES系统无缝对接）。
4.扩展功能与系统兼容性
诊断与维护：
-自检功能：通道状态监测与故障定位（如开路/短路报警）；
-数据记录：内置2 GB闪存（存储历史日志供回溯分析）。
配套设备：
-变送器：VKG20700（信号调理与噪声滤波）；
-云平台：CONiQ®Cloud（支持远程配置与OTA升级）。
.
1.Product positioning and core functions
PORT-789917 is an industrial communication interface module launched by SCHENCK Process GmbH and is a core component of the CONiQ®digital weighing system.Its design goal is to integrate multi-sensor data and high-speed communication,support synchronous signal transmission of weighing sensors,vibration sensors and other devices,adapt to intelligent manufacturing and industrial Internet of Things(IIoT)scenarios,and has redundant communication and real-time diagnostic functions.
2.Inference of key technical parameters
Based on the product line features of Schenk interface module(refer to the VKK 280x series and CONiQ®technical framework):
Communication protocol:
-Support EtherCAT,ProfiNet,Modbus TCP/IP(compatible with mainstream PLC and SCADA systems);
-Optional OPC UA(adapted to cloud platform data interaction).
Channel capacity:
-Support up to 16 sensor inputs(compatible with analog and digital signals);
-Channel isolation:Photoelectric isolation(suppressing common mode interference≥150 Vrms).
Environmental adaptability:
-Protection level:IP67(dust-proof and waterproof,suitable for outdoor cabinet);
-Operating temperature:-30°C to+85°C(wide temperature design).
3.Typical application scenarios
Smart factory integration
-Multi-weight sensor networking(such as real-time monitoring of silo groups);
-Vibration and weight data fusion analysis(predicting the risk of equipment failure).
Logistics and Warehousing
-Automatic three-dimensional warehouse load monitoring(supports real-time feedback from Gigabit Ethernet);
-Dynamic weighing of AGV trolleys(seamlessly connected with the MES system).
4.Extended functionality and system compatibility
Diagnosis and maintenance:
-Self-test function:channel status monitoring and fault positioning(such as open circuit/short circuit alarm);
-Data logging:Built-in 2 GB flash memory(storage historical logs for traceability analysis).
Supporting equipment:
-Transmitter:VKG20700(signal conditioning and noise filtering);
-Cloud platform:CONiQ®Cloud(supports remote configuration and OTA upgrade).
