描述
ProSoft Technology PLX31-EIP-SIE是一款专用通信网关，旨在连接支持EtherNet/IP™的控制器（例如罗克韦尔自动化的ControlLogix或CompactLogix）与西门子®工业以太网网络（连接西门子S7 PAC，例如S7-200、S7-300、S7-400、S7-1200和S7-1500）。
本质上，它充当转换器，允许使用不同工业以太网协议的设备无缝交换数据。
主要产品详情和功能
协议转换：其主要功能是在EtherNet/IP和西门子工业以太网之间进行高速双向数据传输。这消除了集成不同供应商系统时进行复杂编程或规避的需要。
广泛的西门子PLC兼容性：它支持多种西门子S7 PLC，包括S7-200、S7-300、S7-400、S7-1200和S7-1500，使其成为众多西门子控制系统的多功能解决方案。它还可以与配备适当接口的西门子S5控制器配合使用。
数据优先级：该网关具有数据优先级功能，允许您通过为状态和/或控制数据设置特定的RPI（请求数据包间隔）来优化以太网带宽。这确保了关键数据的高效传输。
简化集成：
嵌入式EDS附加配置文件：包含嵌入式EDS（电子数据表）附加配置文件，可简化与EtherNet/IP平台（例如Rockwell Studio 5000 Logix Designer）的集成，并缩短调试时间。
ProSoft Discovery Service：一款实用程序，即使网关不在同一子网内，也能让您的PC发现网关并更改其默认IP地址，从而简化初始设置。
高数据容量：能够交换大量数据，通常支持多达10,000个16位寄存器。
灾难恢复：包含一个SD卡插槽（SD卡可选），用于存储配置文件，有助于快速进行灾难恢复。
坚固耐用的设计：
电源：标称工作电压为24 VDC（允许10至36 VDC），24 VDC时电流负载为300 mA。
工作温度：专为工业环境设计，工作温度范围为-25°C至70°C（-13°F至158°F）。
抗冲击和抗振动：专为承受工业环境而设计，符合IEC 60068-2-27抗冲击标准和IEC 60068-2-6抗振动标准。
电气隔离：为以太网端口提供1500 Vrms隔离，增强在嘈杂环境中的可靠性。
LED指示灯：配备各种LED指示灯，可快速检查状态，包括配置(CFG)、错误(ERR)、电源(PWR)、硬件故障(FLT)、网络状态(NS)、以太网/IP连接状态以及以太网端口链接/活动。
The ProSoft Technology PLX31-EIP-SIE is a specialized communication gateway designed to bridge the gap between EtherNet/IP™-enabled controllers(like Rockwell Automation’s ControlLogix or CompactLogix)and Siemens®Industrial Ethernet networks(connecting to Siemens S7 PACs such as S7-200,S7-300,S7-400,S7-1200,and S7-1500).
Essentially,it acts as a translator,allowing devices using different industrial Ethernet protocols to exchange data seamlessly.
Key Product Details and Functions
Protocol Conversion:Its primary function is high-speed,bi-directional data transfer between EtherNet/IP and Siemens Industrial Ethernet.This eliminates the need for complex programming or workarounds when integrating systems from different vendors.
Broad Siemens PLC Compatibility:It supports a wide range of Siemens S7 PLCs,including S7-200,S7-300,S7-400,S7-1200,and S7-1500,making it a versatile solution for many Siemens-based control systems.It can also be used with Siemens S5 controllers with an appropriate interface.
Data Prioritization:The gateway features data prioritization,allowing you to optimize Ethernet bandwidth by setting specific RPIs(Requested Packet Intervals)for status and/or control data.This ensures critical data is transmitted efficiently.
Simplified Integration:
Embedded EDS Add-On Profile:Includes an embedded EDS(Electronic Data Sheet)Add-On Profile,which simplifies integration into EtherNet/IP platforms(like Rockwell’s Studio 5000 Logix Designer)and reduces commissioning time.
ProSoft Discovery Service:A utility that allows your PC to discover the gateway and change its default IP address even if it’s not on the same subnet,simplifying initial setup.
High Data Capacity:Capable of exchanging large amounts of data,typically supporting up to 10,000 16-bit registers.
Disaster Recovery:Includes an SD card slot(SD card optional)for storing configuration files,which is useful for quick disaster recovery.
Robust Design:
Power Supply:Operates on 24 VDC nominal(10 to 36 VDC allowed),with a current load of 300 mA at 24 VDC.
Operating Temperature:Designed for industrial environments,with an operating temperature range of-25°C to 70°C(-13°F to 158°F).
Shock and Vibration:Built to withstand industrial conditions,meeting IEC 60068-2-27 for shock and IEC 60068-2-6 for vibration.
Electrical Isolation:Provides 1500 Vrms isolation for its Ethernet port,enhancing reliability in noisy environments.
LED Indicators:Equipped with various LED indicators for quick status checks,including Configuration(CFG),Error(ERR),Power(PWR),Hardware Fault(FLT),Network Status(NS),EtherNet/IP connection status,and Ethernet port link/activity.
