描述
1.产品定位与核心功能
1.1应用场景
电力系统自动化：用于变电站综合自动化、发电厂控制、电网调度，实现保护、控制、监测一体化。
过程工业控制：在石油、天然气、化工、冶金等行业中，作为分布式控制系统（DCS）的核心模块，处理模拟量、数字量信号。
高可靠性场景：支持冗余配置，适用于需要连续运行的关键设备，如涡轮机、压缩机、锅炉。
1.2技术亮点
高性能处理能力：基于32位处理器，具备快速逻辑运算与数据处理能力，满足实时控制需求。
模块化设计：支持热插拔，便于维护与扩展，减少系统停机时间。
冗余功能：可选配双机热备冗余，确保单点故障不影响系统运行。
强抗干扰能力：符合IEC 61850、IEC 61131-3等标准，适应电磁干扰、振动、高温等工业环境。
2.技术规格与详细参数
2.1基础参数
参数规格
型号REC650 1MRK008514-AA
制造商ABB AB（瑞典）
系列ABB 800xA/Advant Master系统
处理器类型32位高性能处理器（具体型号需参考技术手册）
内存容量程序存储：≥2MB
数据存储：≥1MB（支持扩展）
I/O容量本地I/O点数：可扩展至数百点（通过扩展模块）
支持模拟量/数字量混合输入输出
通信接口以太网接口：2×10/100Mbps（支持冗余通信）
串行接口：RS-232/RS-485（可选）
现场总线接口：支持PROFIBUS-DP、Modbus TCP/RTU（可选）
电源要求24V DC（-15%/+20%）或110/220V AC（可选），功耗<50W
工作温度-20℃至+60℃（工业级环境适应）
防护等级IP20（需安装在控制柜内）
尺寸（W×H×D）标准机架尺寸（具体需参考安装手册，通常为19英寸机架兼容）
重量约1.5kg（不含扩展模块）
2.2软件与编程支持
编程语言：支持IEC 61131-3标准，包括梯形图（LD）、功能块图（FBD）、结构化文本（ST）等。
开发环境：ABB Control Builder或800xA Engineering软件，提供图形化编程、在线调试、仿真测试功能。
协议支持****：IEC 61850（变电站自动化）、Modbus、DNP3、OPC UA，便于与其他系统集成。
2.3安全与认证
安全标准：符合IEC 61508（SIL 2/3）、ISO 13849-1（PL d/e），适用于功能安全应用。
电磁兼容性：通过IEC 61000-4系列测试，抗干扰能力强。
认证****：CE、UL、cUL、GOST，满足全球主要市场准入要求。
3.产品优势与用户价值
3.1可靠性保障
冗余设计：支持CPU冗余、电源冗余、通信冗余，确保系统99.999%可用性。
自诊断功能：实时监测处理器状态、内存、I/O模块，故障时自动切换备用单元并报警。
长寿命组件：采用工业级元器件，设计寿命>15年，降低全生命周期成本。
1.Product positioning and core functions
1.1 Application scenarios
Power system automation:used for substation integrated automation,power plant control,power grid dispatching,to achieve protection,control,and monitoring integration.
Process industry control:in the oil,gas,chemical,metallurgy and other industries,as the core module of the distributed control system(DCS),it processes analog and digital signals.
High reliability scenario:supports redundant configuration,suitable for key equipment that needs to run continuously,such as turbines,compressors,and boilers.
1.2 Technical highlights
High-performance processing capability:based on a 32-bit processor,it has fast logic operations and data processing capabilities to meet real-time control requirements.
Modular design:supports hot plugging,easy maintenance and expansion,and reduces system downtime.
Redundancy function:optional dual-machine hot standby redundancy to ensure that single point failure does not affect system operation.
Strong anti-interference ability:complies with IEC 61850,IEC 61131-3 and other standards,and adapts to industrial environments such as electromagnetic interference,vibration,and high temperature.
2.Technical specifications and detailed parameters
2.1 Basic parameters
Parameters Specifications
Model REC650 1MRK008514-AA
Manufacturer ABB AB(Sweden)
Series ABB 800xA/Advant Master system
Processor type 32-bit high-performance processor(refer to the technical manual for specific models)
Memory capacity Program storage:≥2MB
Data storage:≥1MB(supports expansion)
I/O capacity Local I/O points:expandable to hundreds of points(through expansion modules)
Support analog/digital mixed input and output
Communication interface Ethernet interface:2×10/100Mbps(supports redundant communication)
Serial interface:RS-232/RS-485(optional)
Fieldbus interface:support PROFIBUS-DP,Modbus TCP/RTU(optional)
Power requirements 24V DC(-15%/+20%)or 110/220V AC(optional),power consumption<50W
Operating temperature-20℃to+60℃(industrial grade environment adaptability)
Protection level IP20(needs to be installed in the control cabinet)
Dimensions(W×H×D)Standard rack size(please refer to the installation manual for details,usually compatible with 19-inch rack)
Weight About 1.5kg(excluding expansion modules)
2.2 Software and programming support
Programming language:Support IEC 61131-3 standard,including ladder diagram(LD),function block diagram(FBD),structured text(ST),etc.
Development environment:ABB Control Builder or 800xA Engineering software,providing graphical programming,online debugging,simulation test functions.
Protocol support****:IEC 61850(substation automation),Modbus,DNP3,OPC UA,easy to integrate with other systems.
2.3 Safety and Certification
Safety standards:Comply with IEC 61508(SIL 2/3),ISO 13849-1(PL d/e),suitable for functional safety applications.
Electromagnetic compatibility:Passed IEC 61000-4 series test,strong anti-interference ability.
Certification****:CE,UL,cUL,GOST,meeting the access requirements of major global markets.
3.Product advantages and user value
3.1 Reliability guarantee
Redundant design:Supports CPU redundancy,power redundancy,and communication redundancy to ensure 99.999%system availability.
Self-diagnosis function:Real-time monitoring of processor status,memory,and I/O modules,automatically switching to backup units and alarming when failure occurs.
Long-life components:Use industrial-grade components with a design life of>15 years to reduce the cost of the entire life cycle.
