描述
一、产品概述
RELIANCE VZ3000G UVZC3455G是Reliance Electric公司（现为ABB旗下品牌）研发的高功率激光二极管驱动模块，专为工业激光应用设计，支持高电流、高电压输出，具备高效能与高可靠性，适用于精密加工、材料标记、焊接等场景。
二、核心功能与技术参数
1.核心功能
高功率驱动：
支持200A电流输出和100V电压，可驱动高功率激光二极管，满足激光加工需求。
多模式控制：
提供恒流、恒功率等控制模式，用户可根据工艺需求灵活调节。
多重保护机制：
内置过电流、过电压、过温度保护功能，确保激光二极管安全运行。
2.技术参数
功率：20kW
效率：>90%
工作温度范围：-20°C至+60°C
防护等级：IP65
接口类型：支持多种工业控制接口（如以太网、数字信号输入/输出）。
3.电气特性
输入电源：AC220V±10%
功耗：2.5W（待机状态）
继电器触点：常开/常闭结点（AC250V/DC30V，5A）。
三、典型应用场景
激光加工
高精度切割、焊接金属、塑料等材料。
材料标记
金属、陶瓷、玻璃等表面的永久性标记。
科研应用
高功率激光实验、光学系统测试。
工业自动化
集成于自动化生产线，实现激光工艺的高效控制。
四、技术优势
高效能设计
采用高效功率转换技术，减少能量损耗，提升系统稳定性。
工业级可靠性
通过IP65防护等级和宽温域适应性设计，适用于恶劣环境。
灵活扩展性
支持多协议通信接口，可与PLC、DCS等系统无缝集成。
RELIANCE VZ3000G UVZC3455G
RELIANCE VZ3000G UVZC3455G
1.Product Overview
RELIANCE VZ3000G UVZC3455G is a high-power laser diode driver module developed by Reliance Electric(now ABB brand).It is specially designed for industrial laser applications,supports high current and high voltage output,has high efficiency and high reliability,and is suitable for precision processing,material marking,welding and other scenarios.
2.Core functions and technical parameters
1.Core functions
High power drive:
Supports 200A current output and 100V voltage,and can drive high-power laser diodes to meet laser processing needs.
Multi-mode control:
Provides constant current and constant power control modes,and users can flexibly adjust according to process needs.
Multiple protection mechanism:
Built-in overcurrent,overvoltage,and overtemperature protection functions to ensure the safe operation of the laser diode.
2.Technical parameters
Power:20kW
Efficiency:>90%
Operating temperature range:-20°C to+60°C
Protection level:IP65
Interface type:Supports multiple industrial control interfaces(such as Ethernet,digital signal input/output).
3.Electrical characteristics
Input power supply:AC220V±10%
Power consumption:2.5W(standby state)
Relay contacts:Normally open/normal closed node(AC250V/DC30V,5A).
3.Typical application scenarios
Laser processing
High-precision cutting,welding metal,plastic and other materials.
Material marking
Permanent markings on surfaces such as metals,ceramics,glass,etc.
Scientific research application
High-power laser experiments and optical system testing.
Industrial automation
Integrated into automated production lines to achieve efficient control of laser processes.
4.Technical advantages
High-performance design
Adopt efficient power conversion technology to reduce energy loss and improve system stability.
Industrial-grade reliability
With IP65 protection rating and wide temperature range adaptability design,it is suitable for harsh environments.
Flexible scalability
Supports multi-protocol communication interface and can be seamlessly integrated with PLC,DCS and other systems.
