SANYO DENKI-770530产品概述
SANYO DENKI-770530是一款高精度绝对值编码器，作为SANYO DENKI旗下SANMOTION E系列的核心产品，专为严苛工业环境下的精密位置检测与实时反馈设计。该产品采用先进光电传感技术与抗干扰电路，核心功能涵盖多圈绝对值测量、动态误差补偿、高速数据输出及环境耐受性增强，所属智能传感平台使其在自动化系统中定位为“关键反馈单元”，通过高精度位置监测与实时数据同步，提升设备的闭环控制精度与运行稳定性，适用于精密机床、机器人关节、电梯控制系统等高精度定位场景，显著降低位置误差与系统延迟，增强运动控制的可靠性与效率。
主要特点和优势
SANYO DENKI-770530的技术特性与竞争优势体现在以下维度：
1.高精度绝对值测量与多圈检测
分辨率达4096线/圈（4096 PPR），多圈计数范围4096圈，总精度≤±0.01°。采用光电绝对编码（AOE）技术，无需初始化即可获取准确位置。
2.动态误差补偿与抗振动设计
内置动态误差补偿算法（DCE），实时修正机械振动导致的测量偏差。抗振动性能达20G（10-2000Hz），适应高频机械运动场景。
3.高速通信与实时反馈
支持BiSS-C、SSI、EtherCAT等多种通信协议，数据更新频率达1MHz。低延迟反馈（≤50μs）满足高速伺服系统需求。
4.高防护与恶劣环境适应性
防护等级IP68，防尘防水设计，耐受高压水冲洗与极端温度（-40℃至85℃）。采用抗腐蚀材料（316L不锈钢外壳），适用于化工、海洋设备等场景。
5.紧凑安装与兼容性设计
法兰尺寸兼容ISO9409标准，轴径可选6-15mm。盲孔/通孔安装方式灵活，节省机械设计空间。
6.冗余信号输出与可靠性增强
双通道信号冗余输出（Redundant Channel），支持故障切换与信号校验，降低系统单点故障风险。
SANYO DENKI-770530 Product Overview
SANYO DENKI-770530 is a high-precision absolute value encoder.As the core product of SANMOTION E series under SANYO DENKI,it is designed for precision position detection and real-time feedback in harsh industrial environments.The product adopts advanced photoelectric sensing technology and anti-interference circuits.The core functions cover multi-turn absolute value measurement,dynamic error compensation,high-speed data output and environmental tolerance enhancement.The intelligent sensing platform makes it positioned as a”key feedback unit”in the automation system.Through high-precision position monitoring and real-time data synchronization,the equipment’s closed-loop control accuracy and operating stability are improved.It is suitable for high-precision positioning scenarios such as precision machine tools,robot joints,and elevator control systems,significantly reducing position errors and system delays,and enhancing the reliability and efficiency of motion control.
Main features and advantages
The technical characteristics and competitive advantages of SANYO DENKI-770530 are reflected in the following dimensions:
1.High-precision absolute value measurement and multi-turn detection
The resolution reaches 4096 wire/roll(4096 PPR),the multi-turn counting range is 4096 turns,and the total accuracy is≤±0.01°.Optoelectronic absolute coding(AOE)technology is used to obtain the exact location without initialization.
2.Dynamic error compensation and vibration resistance design
Built-in dynamic error compensation algorithm(DCE)to correct measurement deviations caused by mechanical vibration in real time.The vibration resistance is up to 20G(10-2000Hz),adapting to high-frequency mechanical motion scenarios.
3.High-speed communication and real-time feedback
Supports various communication protocols such as BiSS-C,SSI,EtherCAT,etc.,and the data update frequency reaches 1MHz.Low latency feedback(≤50μs)meets the needs of high-speed servo systems.
4.High protection and harsh environmental adaptability
Protection level IP68,dust-proof and waterproof design,withstand high-pressure water flushing and extreme temperatures(-40℃to 85℃).It uses corrosion-resistant materials(316L stainless steel shell),which is suitable for chemical,marine equipment and other scenarios.
5.Compact installation and compatibility design
The flange size is compatible with ISO9409 standard,and the shaft diameter is 6-15mm.The blind hole/through hole installation method is flexible,saving space for mechanical design.
6.Redundant signal output and reliability enhancement
Dual-channel signal redundant output(Redundant Channel),supports failover and signal verification,reducing the risk of single-point failure in the system.
