SANYODENKI-767077产品概述
SANYODENKI-767077是一款高性能交流伺服电机，作为SANYO DENKI旗下SANMOTION Q系列的核心产品，专为高刚性、高响应运动控制设计。该产品融合高分辨率编码器与先进伺服算法，核心功能涵盖精准位置控制、高速响应、动态扭矩输出及环境适应性增强，所属中惯量伺服平台使其在自动化系统中定位为“高性能执行单元”，通过优化机械刚性与控制精度，提升设备动态性能与定位稳定性，适用于数控机床、机器人关节、精密输送系统等场景，显著降低振动与响应延迟，实现高效、精准的自动化操作。
主要特点和优势
SANYODENKI-767077的技术特性与竞争优势体现在以下维度：
1.高分辨率编码与精准控制
搭载20位增量式编码器（20bit Incremental Encoder），分辨率达1,048,576脉冲/转。结合矢量控制（Vector Control）技术，定位精度≤±0.001°。
2.高速响应与宽频带驱动
响应频率达3kHz，频响带宽≥1.5kHz。采用高速电流环控制（High-speed Current Loop），动态响应时间≤0.5ms，适配高速加工与精密操作。
3.高扭矩密度与中惯量设计
额定扭矩达15N·m，扭矩密度提升30%。中惯量设计（Medium Inertia）优化加速/减速性能，缩短周期时间20%。
4.动态扭矩补偿与振动抑制
实时动态扭矩补偿（RTC）技术自动补偿负载变化，降低振动幅值≤0.01mm。共振抑制滤波器（Resonance Filter）提升机械稳定性。
5.智能热管理与长寿命设计
内置温度传感器（Thermal Sensor）实时监控，结合自适应热管理算法，延长轴承寿命至50,000小时。采用低损耗磁性材料（Low-loss Magnetic Core），发热量减少25%。
6.高防护与恶劣环境耐受
防护等级IP67，防尘防水，适应油污、粉尘及潮湿环境。工作温度范围-20℃至60℃，满足严苛工业场景需求。
7.节能模式与高效功率转换
支持ECO节能模式（Energy-saving Mode），空载功耗降低至3W。采用高效率功率模块（High Efficiency PMM），功率转换效率≥97%。
8.多协议通信与快速调试
兼容EtherCAT、Profinet等实时通信协议，内置一键调试工具（QCT），参数配置时间缩短至5分钟。
SANYODENKI-767077 Product Overview
SANYODENKI-767077 is a high-performance AC servo motor.As the core product of SANMOTION Q series under SANYO DENKI,it is specially designed for high rigidity and high responsive motion control.The product combines high-resolution encoder and advanced servo algorithms.The core functions cover precise position control,high-speed response,dynamic torque output and enhanced environmental adaptability.The medium-inertia servo platform makes it positioned as a”high-performance execution unit”in the automation system.By optimizing mechanical rigidity and control accuracy,the dynamic performance and positioning stability of the equipment are improved.It is suitable for CNC machine tools,robot joints,precision conveying systems and other scenarios,significantly reducing vibration and response delays,and achieving efficient and accurate automated operations.
Main features and advantages
The technical characteristics and competitive advantages of SANYODENKI-767077 are reflected in the following dimensions:
1.High resolution coding and precise control
Equipped with a 20-bit incremental encoder(20bit Incremental Encoder),the resolution reaches 1,048,576 pulses/rpm.Combined with vector control technology,the positioning accuracy is≤±0.001°.
2.High-speed response and wide-band drive
The response frequency reaches 3kHz and the frequency response bandwidth is≥1.5kHz.High-speed Current Loop is adopted,with a dynamic response time of≤0.5ms,suitable for high-speed machining and precision operation.
3.High torque density and medium inertia design
The rated torque reaches 15N·m,and the torque density is increased by 30%.Medium Inertia design optimizes acceleration/deceleration performance,shortening cycle time by 20%.
4.Dynamic torque compensation and vibration suppression
Real-time dynamic torque compensation(RTC)technology automatically compensates for load changes,reducing vibration amplitude≤0.01mm.Resonance Filter improves mechanical stability.
5.Intelligent thermal management and long-life design
Built-in temperature sensor(Thermal Sensor)real-time monitoring,combined with adaptive thermal management algorithm,extends the bearing life to 50,000 hours.Low-loss Magnetic Core is used to reduce heat generation by 25%.
6.High protection and harsh environmental tolerance
Protection level IP67,dust-proof and waterproof,adapted to oil,dust and humid environments.The operating temperature range is-20℃to 60℃,meeting the demands of strict industrial scenarios.
7.Energy-saving mode and efficient power conversion
Supports ECO energy-saving mode(Energy-saving Mode),and the no-load power consumption is reduced to 3W.High Efficiency PMM is used,and the power conversion efficiency is≥97%.
8.Multi-protocol communication and rapid debugging
Compatible with real-time communication protocols such as EtherCAT and Profinet,it has a built-in one-click debugging tool(QCT),and the parameter configuration time is shortened to 5 minutes.
