描述
1.产品定位与核心功能
SCHENCK 784618是申克（SCHENCK Process GmbH）推出的高精度工业称重传感器，推测属于SB4柱式传感器或DMA动态称重模块衍生型号。其设计目标为高动态响应与抗振动干扰，适用于轨道交通、电力设备等需实时监测的场景，精度等级达C3（误差≤0.02%），并具备宽量程与快速响应特性。
2.关键技术参数推断
基于申克公开产品线特征（未明确标注784618，但符合以下系列技术规律）：
量程范围：
-推测为1–100 t（参考SB4柱式传感器量程规律）；
-可选高频响应版本（适配振动筛分设备动态称重）。
精度与认证：
-分度数：C3（3000分度）；
-认证：OIML R60、IEC 60068-2（振动/冲击测试达标）。
环境适应性：
-防护等级：IP67（防粉尘与短期浸水）；
-工作温度：-30°C至+85°C（宽温设计，适配户外设备）。
3.典型应用场景
电力与铁路行业
-发电机组振动监测与重量补偿（动态误差≤0.1%）；
-机车轴重实时测量（支持10–100 km/h行驶速度）。
矿山与建材加工
-振动筛分机载荷监控（抑制50–200 Hz机械振动干扰）；
-料斗称重系统（如水泥厂熟料计量）。
4.系统集成与扩展功能
接口与通信：
-数字输出：EtherCAT、SERCOS III（支持高频率数据传输）；
-模拟输出：4–20 mA（兼容传统工业仪表）。
配套设备：
-前置器：VKG20700（信号调理与抗噪声处理）；
-云平台：CONiQ®Cloud（实时数据可视化与远程诊断）。
1.Product positioning and core functions
SCHENCK 784618 is a high-precision industrial weighing sensor launched by SCHENCK Process GmbH.It is probably a derivative model of SB4 column sensor or DMA dynamic weighing module.Its design goal is high dynamic response and anti-vibration interference.It is suitable for scenes such as rail transit and power equipment that require real-time monitoring.It has an accuracy level of C3(Error≤0.02%)and has wide range and fast response characteristics.
2.Inference of key technical parameters
Based on Schenker’s public product line features
Range range:
-Presumably 1–100 t(refer to the range law of SB4 column sensor);
-Available in high frequency response version(adapted to dynamic weighing of vibration screening equipment).
Accuracy and certification:
-Number of grades:C3(3000 grades);
-Certification:OIML R60,IEC 60068-2(vibration/impact test meets the standards).
Environmental adaptability:
-Protection level:IP67(dow against dust and short-term water immersion);
-Operating temperature:-30°C to+85°C(wide temperature design,suitable for outdoor equipment).
3.Typical application scenarios
Electricity and Railway Industry
-Generator vibration monitoring and weight compensation(dynamic error≤0.1%);
-Real-time measurement of the axle weight of the locomotive(supports 10–100 km/h driving speed).
Mine and building materials processing
-Vibrating screener load monitoring(suppresses mechanical vibration interference at 50–200 Hz);
-Hopper weighing system(such as cement plant clinker measurement).
4.System integration and extension functions
Interface and communication:
-Digital output:EtherCAT,SERCOS III(supports high-frequency data transmission);
-Analog output:4–20 mA(compatible with traditional industrial instruments).
Supporting equipment:
-Preloader:VKG20700(signal conditioning and anti-noise processing);
-Cloud platform:CONiQ®Cloud(real-time data visualization and remote diagnosis).
