描述
1.产品定位与核心功能
SCHENCK 784719是申克（Schenck Process GmbH）推出的高精度称重传感器，专为工业自动化场景设计，适用于动态与静态称重系统。其核心优势在于长寿命设计（可达30年）与强环境适应性（IP68防护等级），尤其适合矿山、冶金、化工等严苛工况。
2.关键技术参数
量程范围：
-推测为10吨级（参考申克RTN系列型号规律，如RTN 10 t D726176.04）；
-允许误差：静态精度±0.1%（双转向架称重场景）。
传感器类型：
-轴对称称重传感器（RT系列或RTNC3型号衍生款）；
-输出信号：4–20 mA或数字信号（支持RS485/ProfiBus接口）。
机械特性：
-外壳材质：不锈钢（耐腐蚀与高温）；
-安装方式：螺纹固定或法兰盘适配（兼容轨道衡、料仓称重系统）。
3.典型应用场景
动态轨道衡系统
-用于铁水罐车动态称重（行驶速度4–8 km/h），精度达±0.5%；
-支持高炉与炼钢厂间的物料总量平衡计算。
工业生产线计量
-搭配皮带输送机实现连续物料称重（如矿山筛分、化工配料）；
-抗冲击与振动干扰能力突出（适配矿山、港口环境）。
4.系统集成与扩展性
配套设备：
-接线盒：VKK 280x系列（支持多传感器组网，如VKK 28014铸铝款）；
-控制器：VEG20650/VIF20650（带以太网与总线通讯功能）。
软件支持：
-SCHENCK ONE测量软件（支持云服务与数字化参数配置）；
-DISOMAT系列仪表（适配多任务实时操作系统）。
1.Product positioning and core functions
SCHENCK 784719 is a high-precision weighing sensor launched by Schenck Process GmbH.It is designed for industrial automation scenarios and is suitable for dynamic and static weighing systems.Its core advantage lies in its long-life design(up to 30 years)and strong environmental adaptability(IP68 protection level),which is especially suitable for harsh working conditions such as mining,metallurgy,and chemical industry.
2.Key technical parameters
Range range:
-It is speculated to be 10 tons(refer to the Schenk RTN series model rules,such as RTN 10 t D726176.04);
-Allowable error:Static accuracy±0.1%(double bogie weighing scenario).
Sensor type:
-Axisymmetric load cell(RT series or RTNC3 model derivative);
-Output signal:4–20 mA or digital signal(supports RS485/ProfiBus interface).
Mechanical characteristics:
-Shell material:stainless steel(corrosion resistance and high temperature);
-Installation method:threaded fixation or flange adaptation(compatible with track scale and silo weighing systems).
3.Typical application scenarios
Dynamic track scale system
-Used for dynamic weighing of molten iron tank trucks(driving speed 4–8 km/h),with an accuracy of±0.5%;
-Supports calculation of total material balance between blast furnace and steel mill.
Industrial production line measurement
-Use belt conveyor to achieve continuous material weighing(such as mine screening,chemical ingredients);
-Excellent resistance to shock and vibration interference(adapted to mine and port environment).
4.System integration and scalability
Supporting equipment:
-Terminal box:VKK 280x series(supports multi-sensor networking,such as VKK 28014 cast aluminum model);
-Controller:VEG20650/VIF20650(with Ethernet and bus communication function).
Software support:
-SCHENCK ONE measurement software(supports cloud services and digital parameter configuration);
-DISOMAT series instrumentation(adapted to multitasking real-time operating system).
