描述
1.产品定位与核心功能
SCHENCK 784825是申克（SCHENCK Process GmbH）推出的高可靠性工业称重传感器，推测属于DWB梁式传感器或VBB波纹管系列衍生型号。其设计目标为高精度静态称重，适用于料仓、反应釜等固定设备的重量监测，精度等级达C3（误差≤0.02%），并具备抗侧向力优化特性。
2.关键技术参数推断
基于申克公开产品线特征
量程范围：
-推测为5–100 t（参考DWB系列梁式传感器量程规律）；
-可选小量程型号（如0.5–50 t，适配VBB波纹管系列）。
精度与认证：
-分度数：C3（3000分度）；
-认证：OIML R60、IECEx（防爆等级Zone 1/21）。
环境适应性：
-防护等级：IP68（完全防水防尘）；
-工作温度：-20°C至+60°C（标准工业级范围）。
3.典型应用场景
化工料仓称重
-实时监测反应釜物料重量（精度±0.1%）；
-支持有毒液体存储罐的安全超限报警。
食品加工行业
-配料系统静态称量（如奶粉、调味料±0.05%误差控制）；
-符合FDA卫生标准（不锈钢密封设计）。
4.系统集成与扩展功能
接口与通信：
-数字输出：Modbus RTU、CANopen（适配现代PLC系统）；
-模拟输出：0–10 V/mV/V（兼容传统仪表）。
配套设备：
-接线盒：VKK 280x系列（支持多传感器并联与信号隔离）；
-变送器：VKG20650（带振动抑制与温度补偿）。
1.Product positioning and core functions
SCHENCK 784825 is a high-reliability industrial weighing sensor launched by SCHENCK Process GmbH,which is presumably a derivative model of DWB beam sensor or VBB corrugated tube series.Its design goal is high-precision static weighing,suitable for weight monitoring of fixed equipment such as silos and reactors,with an accuracy level of C3(Error≤0.02%),and has the characteristics of lateral force optimization.
2.Inference of key technical parameters
Based on Schenker’s public product line features
Range range:
-Presumably 5–100 t(refer to the range law of the DWB series beam sensor);
-Optional small range models(such as 0.5–50 t,suitable for VBB bellows series).
Accuracy and certification:
-Number of grades:C3(3000 grades);
-Certification:OIML R60,IECEx(Explosion-proof Grade Zone 1/21).
Environmental adaptability:
-Protection level:IP68(fully waterproof and dustproof);
-Operating temperature:-20°C to+60°C(standard industrial grade range).
3.Typical application scenarios
Chemical silo weighing
-Real-time monitoring of the weight of reactor material(accuracy±0.1%);
-Supports safety over-limit alarm for toxic liquid storage tanks.
Food Processing Industry
-Static weighing of ingredients system(such as milk powder and seasoning±0.05%error control);
-Comply with FDA hygiene standards(stainless steel seal design).
4.System integration and extension functions
Interface and communication:
-Digital output:Modbus RTU,CANopen(adapted to modern PLC systems);
-Analog output:0–10 V/mV/V(compatible with traditional instruments).
Supporting equipment:
-Terminal box:VKK 280x series(supports multi-sensor parallel connection and signal isolation);
-Transmitter:VKG20650(with vibration suppression and temperature compensation).
