描述
SCHNEIDER MC-41110400是施耐德的一款伺服驱动器，属于PacDrive MC-4系列。以下是其产品详情：
基本参数：
额定连接电压：3AC 380V(-10%)至480V(+10%)
控制电压：DC 24V(-15%/+25%)
控制电流：1A（DC 24V供电部分）
额定输出电流：10A
输出电压：0-480VAC
输出频率：0-600Hz
通信接口：集成SERCOS接口，通过光纤与PacDrive控制器通信，支持高速实时运动总线。
电机兼容性：具备自动电机识别功能，可与施耐德PacDrive伺服电机，如SM/SH系列配合使用。
过载能力：通常支持250%的峰值过载能力，以应对高动态负载。
防护等级：IP20，需安装在控制柜内。
散热方式：内部风扇强制散热或自然对流，取决于具体功率和安装情况。
安装方式：紧凑型设计，支持壁挂式安装。
尺寸重量：约100mm(宽)×400mm(高)×320mm(深)，重量约3.1kg。
该驱动器将电源单元、功率级和单轴伺服调节器封装在一个紧凑外壳内，可节省控制柜空间，简化布线。其基于SERCOS总线能实现高速实时通讯，具有高动态响应和高精度定位等卓越的运动控制性能，适用于包装机械、数控机床等对运动控制要求较高的自动化设备。
The SCHNEIDER MC-41110400 is a Schneider servo drive,part of the PacDrive MC-4 series.The following are product details:
Basic Parameters:
Rated Connection Voltage:3AC 380V(-10%)to 480V(+10%)
Control Voltage:DC 24V(-15%/+25%)
Control Current:1A(DC 24V power supply)
Rated Output Current:10A
Output Voltage:0-480VAC
Output Frequency:0-600Hz
Communication Interface:Integrated SERCOS interface,communicating with the PacDrive controller via fiber optic cable,supporting high-speed real-time motion bus.
Motor Compatibility:Features automatic motor identification and is compatible with Schneider PacDrive servo motors,such as the SM/SH series.
Overload Capacity:Typically supports a peak overload capacity of 250%to handle high dynamic loads.
Protection Rating:IP20,requires installation in a control cabinet.Cooling:Internal fan-driven forced cooling or natural convection,depending on the specific power and installation situation.
Mounting:Compact design,supports wall mounting.
Dimensions and Weight:Approximately 100mm(width)×400mm(height)×320mm(depth),weighing approximately 3.1kg.
This drive integrates the power supply unit,power stage,and single-axis servo regulator into a compact housing,saving control cabinet space and simplifying wiring.Its SERCOS bus-based design enables high-speed real-time communication and delivers superior motion control performance,including high dynamic response and high-precision positioning.It is suitable for automation equipment with demanding motion control requirements,such as packaging machinery and CNC machine tools.
