描述
Schneider TSXMFPP004M产品详情
1.产品概述
Schneider TSXMFPP004M是施耐德电气（Schneider Electric）旗下TSX系列PLC的内存扩展卡，主要用于扩展控制器的程序存储和数据处理能力。该模块支持高可靠性工业控制场景，适用于电力、机械制造、化工、能源管理等领域，可与施耐德TSX系列PLC主机（如TSXIO8110、TSXIO8120）配合使用。
2.技术规格
参数描述
型号TSXMFPP004M
品牌施耐德（Schneider Electric）
功能类型内存扩展卡（支持程序与数据存储）
结构形式模块式（兼容TSX系列机架）
安装方式现场安装（需配合TSX PLC主机）
工作电压24 V DC（需通过TSX电源模块供电）
环境适应性温度：0°C～55°C，湿度：10%～90%（非凝露）
认证标准CE、RoHS、IEC 61131-3
3.功能特性
（1）扩展存储能力
支持程序与数据的独立存储，提升PLC系统的复杂控制任务处理能力。
兼容TSX系列主机的冗余配置，增强系统可靠性。
（2）工业级设计
抗电磁干扰设计，适用于强电磁环境。
支持宽温运行，适应工业现场温度波动。
（3）灵活兼容性
适配施耐德TSXIO8110、TSXIO8120等主机，可扩展至多机架系统。
兼容Unity Pro、SoMachine等编程软件。
4.应用场景
工业自动化
大型生产线逻辑控制、多设备协同操作。
能源管理
电力系统实时数据存储与分析。
化工与食品加工
复杂工艺流程的程序与数据管理。
楼宇自动化
智能建筑系统长期运行数据存储。
Schneider TSXMFPP004M Product Details
1.Product Overview
Schneider TSXMFPP004M is a memory expansion card for Schneider Electric’s TSX series PLC,mainly used to expand the controller’s program storage and data processing capabilities.This module supports high-reliability industrial control scenarios and is suitable for power,machinery manufacturing,chemical industry,energy management and other fields.It can be used with Schneider TSX series PLC hosts(such as TSXIO8110,TSXIO8120).
2.Technical Specifications
Parameter Description
Model TSXMFPP004M
Brand Schneider Electric
Function Type Memory expansion card(supports program and data storage)
Structural form Modular(compatible with TSX series racks)
Installation method On-site installation(needs to be used with TSX PLC host)
Working voltage 24 V DC(needs to be powered by TSX power supply module)
Environmental adaptability Temperature:0°C~55°C,humidity:10%~90%(non-condensing)
Certification standards CE,RoHS,IEC 61131-3
3.Functional characteristics
(1)Expanded storage capacity
Supports independent storage of programs and data,and improves the PLC system’s ability to handle complex control tasks.
Compatible with the redundant configuration of the TSX series host to enhance system reliability.
(2)Industrial-grade design
Anti-electromagnetic interference design,suitable for strong electromagnetic environments.
Supports wide temperature operation and adapts to temperature fluctuations in industrial sites.
(3)Flexible compatibility
Adaptable to Schneider TSXIO8110,TSXIO8120 and other hosts,expandable to multi-rack systems.
Compatible with Unity Pro,SoMachine and other programming software.
4.Application scenarios
Industrial automation
Logical control of large production lines,collaborative operation of multiple devices.
Energy management
Real-time data storage and analysis of power systems.
Chemical and food processing
Program and data management of complex process flows.
Building automation
Long-term operation data storage of intelligent building systems.
