描述
SQUARED PMD-32是施耐德旗下Square D品牌的一款功率表显示模块，属于PowerLogic 3020系列。以下是其产品详情：
功能特点：作为PowerLogic 3020系列功率表的可选附加显示模块，可通过电缆与功率表连接，为功率表提供本地数据读取功能，还可作为功率表编程器。支持设置、概述、诊断、重置、报警设置、报警日志、电能质量值、需量值、功率值等多种操作模式，方便用户对功率表进行参数配置、数据监测与故障排查等。
技术参数：工作电压为220V，输出频率为50Hz，脉冲常数范围是0至327.67kWh，密码范围为0至9998，适用于低压和中压应用，精度偏差为0.25%。
外观设计：前面板有5个按钮，包括模式按钮、两个箭头按钮、选择按钮和对比度按钮，可用于在不同模式间切换、增减显示参数、进入所选模式以及调整显示屏对比度。配备两行LCD显示屏，用于显示相关数据和信息。
尺寸重量：尺寸约为11.1cm×11.1cm×3.2cm，重量约0.2kg。
安装方式：可通过电缆与功率表连接，电缆长度通常为0.3米，该电缆同时提供通信和电源，安装简便，支持即插即用。
The SQUARED PMD-32 is a power meter display module from Schneider’s Square D brand,part of the PowerLogic 3020 series.Product details are as follows:
Features:As an optional add-on display module for the PowerLogic 3020 series power meter,it connects to the meter via a cable,providing local data reading capabilities and also serving as a power meter programmer.It supports multiple operating modes,including setup,overview,diagnostics,reset,alarm settings,alarm log,power quality,demand,and power values,allowing users to easily configure power meter parameters,monitor data,and troubleshoot.
Technical Parameters:Operating voltage:220V,output frequency:50Hz,pulse constant range:0 to 327.67kWh,password range:0 to 9998,suitable for low and medium voltage applications,with an accuracy tolerance of 0.25%.Design:The front panel features five buttons:a mode button,two arrow buttons,a select button,and a contrast button.These buttons are used to switch between modes,increase or decrease displayed parameters,enter the selected mode,and adjust the display contrast.A two-line LCD display is provided for displaying relevant data and information.
Dimensions and Weight:Approximately 11.1 cm×11.1 cm×3.2 cm,weighing approximately 0.2 kg.
Installation:Connects to the power meter via a cable,typically 0.3 meters in length.This cable provides both communication and power,making installation simple and plug-and-play.
