描述
SQUARED PMD-32是施耐德电气（Schneider Electric）旗下Square D品牌的一款电力监测显示模块，属于PowerLogic 3020系列。以下是其产品详情：
基本信息
品牌：Square D
型号：PMD-32
系列：PowerLogic 3020
部件号：3020-PMD-32
技术参数
工作电压：220V
频率范围：50Hz和60Hz（默认60Hz）
脉冲常数范围：0至327.67kWh（默认0kWh）
密码范围：0至9998（默认0）
功能特点
显示功能：配备两行LCD显示屏，可显示电压、电流、能耗等关键电力参数，还能显示需求值、电能质量值、最小和最大值等。
操作模式：支持设置、汇总和诊断等多种操作模式，方便用户进行参数配置、故障排查和数据查看。
按键操作：前面板设有5个按钮，包括模式按钮、两个箭头按钮、选择按钮和对比度按钮，便于用户在不同模式间切换、调整显示参数、进入选定模式以及调节屏幕对比度。
编程功能：可作为电力仪表编程器，对电力仪表进行设置，如重置峰值需求、累计能量和最小/最大值等。
其他信息
应用领域：适用于工业领域的低压和中压应用，精度偏差为0.25%。
连接方式：通过一根0.3米的电缆与PowerLogic电力仪表连接，同时提供通信和电力。
尺寸重量：尺寸约为127mm×127mm×127mm，重量约0.45kg。
The SQUARED PMD-32 is a power monitoring and display module from the Square D brand of Schneider Electric,part of the PowerLogic 3020 series.The following are product details:
Basic Information
Brand:Square D
Model:PMD-32
Series:PowerLogic 3020
Part Number:3020-PMD-32
Technical Parameters
Operating Voltage:220V
Frequency Range:50Hz and 60Hz(Default:60Hz)
Pulse Constant Range:0 to 327.67kWh(Default:0kWh)
Password Range:0 to 9998(Default:0)
Features
Display:Equipped with a two-line LCD display,it displays key power parameters such as voltage,current,and energy consumption,as well as demand values,power quality,and minimum and maximum values.
Operation Mode:Supports multiple operation modes,including setup,summary,and diagnostics,facilitating parameter configuration,troubleshooting,and data review.Key Operation:The front panel features five buttons:a mode button,two arrow buttons,a select button,and a contrast button.These buttons facilitate switching between modes,adjusting display parameters,entering the selected mode,and adjusting screen contrast.
Programming Function:This device can be used as a power meter programmer to configure meter settings,such as resetting peak demand,accumulated energy,and minimum/maximum values.
Other Information
Applications:Suitable for low-and medium-voltage applications in industrial applications,with an accuracy tolerance of 0.25%.
Connection:Connects to PowerLogic power meters via a 0.3-meter cable,providing both communication and power.
Dimensions and Weight:Approximately 127 mm×127 mm×127 mm,weighs approximately 0.45 kg.
