描述
以下是其产品详情：
基本信息
品牌：SIMCO
类型：静电场测试仪
尺寸：11.5cm×6.5cm×2.5cm
重量：0.13kg（连电池）
外壳材质：导电树脂（ABS）
技术参数
输入电压：9V，6F22锰电池
静电场测量范围：±（0.00-20.0）kV（自动显示调整）
标准测距：25mm±1mm
离子平衡测量范围：±（0-200）V
反应时间：＜1秒
LCD显示更新：每秒5次
精确度：±10%
工作温湿度：10-40℃，相对湿度0-60%
自动关机：闲置约5分钟
功能特点
测量功能多样：可测量静电场和离子平衡电压，通过连接离子平衡测量板，按下“IB”按钮可转换至离子平衡测量模式。
操作简便：内置微控处理器，通过红色电源（POWER）按钮开关，灰色返零（ZERO）按钮调整零点，绿色冻结显示（HOLD）按钮锁定数据。
显示清晰：LCD显示有数字和图形，正电荷用红色显示，负电荷用蓝色显示，在暗黑环境下可点亮面板显示灯光。
测量距离精准：置有2个LED灯，用于确定测量距离为25mm，确保测量的准确性。
安全可靠：外壳为导电材质，并有接地扣，确保测量结果正确可靠，还具有开机、闲置自动关机、超出可测范围等声响报警功能。
The following are product details:
Basic Information
Brand:SIMCO
Type:Electrostatic Field Tester
Dimensions:11.5cm×6.5cm×2.5cm
Weight:0.13kg(with battery)
Casing Material:Conductive Resin(ABS)
Technical Parameters
Input Voltage:9V,6F22 manganese battery
Electrostatic Field Measurement Range:±(0.00-20.0)kV(Automatic Display Adjustment)
Standard Measurement Range:25mm±1mm
Ion Balance Measurement Range:±(0-200)V
Response Time:<1 second
LCD Display Update:5 times per second
Accuracy:±10%
Operating Temperature and Humidity:10-40°C,Relative Humidity 0-60%
Auto Power Off:Approximately 5 minutes of inactivity
Features
Diverse Measurement Functions:Capable of measuring electrostatic field and ion balance voltage.Connecting the ion balance measurement board and pressing the”IB”button switches to ion balance measurement mode.Easy Operation:Built-in microcontroller.Use the red POWER button to turn the meter on and off,the gray ZERO button to adjust the zero point,and the green HOLD button to freeze the display.
Clear Display:The LCD displays both numbers and graphs,with positive charges indicated in red and negative charges in blue.A panel display illuminates in dark environments.
Precise Distance Measurement:Two LEDs confirm the measurement distance is within 25mm,ensuring accurate measurements.
Safe and Reliable:The housing is made of conductive material and has a grounding clip to ensure accurate and reliable measurements.It also features audible alarms for power on,automatic shutdown when idle,and when out of range.
