描述
TeIKOOR CPCIAC-6U-500 900-7002-10很可能是一款CompactPCI(cPCI)电源(PSU)，专为工业和加固应用而设计。
以下是该型号通常含义的详细说明：
TeIKOOR：这是制造商Telkoor Power Supplies（有时会拼写错误为“Teikoor”）。Telkoor以生产用于军事、航空航天和工业应用的高质量、加固型电源解决方案而闻名。
CPCIAC-6U-500：型号的这一部分给出了核心规格：
CPCI（CompactPCI）：指的是外形尺寸。CompactPCI是一种基于PCI技术的高性能模块化工业总线标准。它广泛应用于嵌入式系统、电信和工业自动化领域，这些领域注重可靠性、模块化和热插拔功能。
AC：表示电源采用交流(AC)输入。
6U：指模块在cPCI机箱内的物理尺寸或高度。6U模块比3U模块更高，通常占用更多空间。
500：这很可能表示最大连续输出功率（以瓦特为单位），这意味着它可以为CompactPCI系统提供高达500瓦的功率。
900-7002-10：这可能是特定电源配置的特定部件号、修订代码或内部制造代码。
主要产品详情和功能
工业级电源：这款电源专为严苛环境而设计，坚固可靠。这通常意味着它可以承受：
宽工作温度范围（例如，全功率下为-5°C至+55°C，有时在更高温度下会降额）。
振动和冲击。
电磁干扰(EMI)。
符合PICMG标准：作为CompactPCI电源，它符合PICMG 2.11电源接口规范。这确保了cPCI系统内良好的兼容性和热插拔功能。
高效率：Telkoor的电源通常设计为高效率（例如，高于81%），从而减少了发热量和能耗。
多种输出电压：cPCI电源可提供cPCI背板及其所插卡所需的各种直流输出电压。常见输出包括：
+5V（通常输出极高电流，例如高达60A或80A）
+3.3V（通常输出极高电流，例如高达60A或80A）
+12V
-12V
功率因数校正(PFC)：大多数现代工业电源，尤其是超过一定功率等级的电源，都包含功率因数校正(PFC)，以改善电源质量并降低谐波失真。
热插拔功能：这是cPCI系统中一项至关重要的功能。它允许在系统运行时插入或移除电源模块，而无需关闭整个系统，这对于系统正常运行和维护至关重要。
N+1冗余支持：许多cPCI电源，包括Telkoor型号，都支持N+1冗余。这意味着您可以安装一个额外的电源模块(N+1)来提供备用电源。如果一个电源发生故障，冗余电源将自动接管，确保电源持续运行。该功能通常包括关键输出（例如+5V和+3.3V）的主动均流，以平衡并联电源之间的负载。
保护功能：包含全面的保护电路：
过压保护(OVP)
过流保护(OCP)
短路保护(SCP)
过温保护(OTP)
状态指示灯：通常配备LED指示灯（例如，绿色表示“电源良好”，琥珀色/红色表示“过温”或“故障”），可快速查看电源状态。
监控和控制（可选）：部分高端型号可能包含I²C数据总线，用于远程监控电压、电流和温度，以及配置电源。
典型应用
TeIKOOR CPCIAC-6U-500适用于各种依赖CompactPCI架构的关键工业、电信和军事应用：
电信基础设施：为局端设备、基站和网络交换机供电。
工业自动化：为工厂、过程控制和机器人中的工业PC、控制器和数据采集系统供电。
国防和航空航天：用于航空电子设备、地面车辆和关键任务系统的加固型嵌入式系统。
测试和测量设备：为高精度测试台和测量仪器提供稳定的电源。
医疗设备：用于采用模块化计算的先进医学成像或诊断设备。
The TeIKOOR CPCIAC-6U-500 900-7002-10 is very likely a CompactPCI(cPCI)power supply unit(PSU),specifically designed for industrial and ruggedized applications.
Here’s a breakdown of what that model number typically implies:
TeIKOOR:This is the manufacturer,Telkoor Power Supplies(though sometimes misspelled as”Teikoor”).Telkoor is known for producing high-quality,rugged power solutions for military,aerospace,and industrial applications.
CPCIAC-6U-500:This part of the model number gives us the core specifications:
CPCI(CompactPCI):This refers to the form factor.CompactPCI is a high-performance,modular industrial bus standard based on PCI technology.It’s widely used in embedded systems,telecommunications,and industrial automation where reliability,modularity,and hot-swap capabilities are important.
AC:Indicates that the power supply takes an Alternating Current(AC)input.
6U:Refers to the physical size or height of the module within a cPCI chassis.A 6U module is taller than a 3U module and typically occupies more space.
500:This most likely indicates the maximum continuous output power in Watts,meaning it can deliver up to 500 Watts of power to the CompactPCI system.
900-7002-10:This is likely a specific part number,revision code,or internal manufacturing code for this particular configuration of the power supply.
Key Product Details and Functions
Industrial-Grade Power Supply:Designed for demanding environments,this PSU is built to be robust and reliable.This typically means it can withstand:
Wide operating temperature ranges(e.g.,-5°C to+55°C at full power,sometimes with derating for higher temperatures).
Vibration and shock.
Electromagnetic interference(EMI).
Compliance with PICMG Standards:As a CompactPCI power supply,it adheres to the PICMG 2.11 power interface specification.This ensures proper compatibility and hot-swap functionality within a cPCI system.
High Efficiency:Telkoor’s power supplies are often designed for high efficiency(e.g.,better than 81%),which reduces heat generation and energy consumption.
Multiple Output Voltages:A cPCI power supply provides various DC output voltages required by the cPCI backplane and the cards plugged into it.Common outputs include:
+5V(often with very high current output,e.g.,up to 60A or 80A)
+3.3V(often with very high current output,e.g.,up to 60A or 80A)
+12V
-12V
Power Factor Correction(PFC):Most modern industrial PSUs,especially those over a certain power level,include Power Factor Correction(PFC)to improve power quality and reduce harmonic distortion.
Hot-Swap Capability:This is a crucial feature in cPCI systems.It allows the power supply module to be inserted or removed while the system is running,without shutting down the entire system,which is vital for system uptime and maintenance.
N+1 Redundancy Support:Many cPCI PSUs,including Telkoor models,support N+1 redundancy.This means you can install an extra power supply module(N+1)to provide backup power.If one unit fails,the redundant unit automatically takes over,ensuring continuous operation.This feature often includes active current sharing on key outputs(like+5V and+3.3V)to balance the load among parallel PSUs.
Protection Features:Includes comprehensive protection circuits:
Over-voltage protection(OVP)
Over-current protection(OCP)
Short-circuit protection(SCP)
Over-temperature protection(OTP)
Status Indicators:Typically features LED indicators(e.g.,green for”power good,”amber/red for”over-temperature”or”fault”)for quick visual status checks.
Monitoring and Control(Optional):Some high-end models may include an I²C data bus for remote monitoring of voltage,current,and temperature,and for configuring the PSU.
Typical Applications
The TeIKOOR CPCIAC-6U-500 is used in various critical industrial,telecommunication,and military applications that rely on CompactPCI architecture:
Telecommunications Infrastructure:For power delivery in central office equipment,base stations,and network switches.
Industrial Automation:Powering industrial PCs,controllers,and data acquisition systems in factories,process control,and robotics.
Defense and Aerospace:In ruggedized embedded systems for avionics,ground vehicles,and mission-critical systems.
Test and Measurement Equipment:Providing stable power for high-precision test benches and measurement instruments.
Medical Devices:In advanced medical imaging or diagnostic equipment that use modular computing.
