描述
一、产品定位与核心功能
1.目标应用场景
石油化工装置安全控制：
用于催化裂化、加氢裂化、乙烯裂解等高危工艺装置，在超温、超压、泄漏等异常工况下触发紧急停车（ESD），防止爆炸、火灾等灾难性事故。
天然气处理与输送：
在天然气压缩站、管道调压站中，监测压力、流量、可燃气体浓度，通过燃烧管理系统（BMS）控制点火、熄火、燃气切断，确保设备安全运行。
核电站辅助系统：
用于核反应堆冷却剂泵、蒸汽发生器等关键设备的安全级控制，满足IEC 61513（核电厂安全系统标准）要求。
2.核心功能
三重模块化冗余（TMR）架构：
模块内部集成3个独立通道（A/B/C），每个通道包含CPU、I/O、通信接口，通过表决机制（2/3逻辑）实现故障容错。即使单个通道故障，系统仍可无扰动运行，避免误停车或漏停车。
高速故障检测与诊断：
支持实时自诊断（如电源、通信、传感器故障），检测时间<10ms，并通过HART协议或Modbus将故障信息上传至操作员站，指导快速维护。
安全完整性等级（SIL）认证：
获得TÜV Rheinland、Exida等机构认证，符合IEC 61508（功能安全标准）、ISA S84（过程工业安全标准），可实现SIL 3级安全功能（风险降低因子>1000）。
热插拔与在线更换：
模块支持带电插拔，无需停机即可更换故障模块，减少非计划停机时间，提升系统可用性（>99.999%）。
二、技术规格与性能参数
1.硬件规格
处理器性能：
每个通道搭载32位RISC处理器，主频200MHz，处理能力>1000条指令/ms，满足高速安全逻辑运算需求（如PID控制、联锁逻辑）。
I/O容量：
数字量输入（DI）：支持24V DC信号，单模块最多32通道，响应时间<1ms。
数字量输出（DO）：支持继电器或固态输出，单模块最多16通道，负载能力2A/24V DC。
模拟量输入（AI）：支持4-20mA、0-10V信号，单模块最多8通道，精度±0.1%FS，采样率100次/秒。
通信接口：
前面板：1×RS-485接口（Modbus RTU协议），用于与第三方设备通信。
后面板：1×以太网接口（100Mbps，冗余配置），支持Triconex专有协议，与工程师站、操作员站实时数据交互。
环境适应性：
工作温度：-20℃至+70℃（工业级），可选-40℃至+85℃（扩展级），适应户外或极端环境。
防护等级：IP66（防尘防水），符合NEMA 4X标准，适用于腐蚀性气体或潮湿场所。
2.软件功能
安全逻辑编程：
使用Triconex TriStation 1131软件，支持功能块图（FBD）、梯形图（LD）、顺序功能图（SFC）等IEC 61131-3标准编程语言，简化安全逻辑开发。
在线调试与仿真：
提供离线仿真功能，可在PC端模拟输入信号，验证安全逻辑正确性，减少现场调试时间。
历史数据记录：
内置非易失性存储器（NVM），可记录最近1000条故障事件（包括时间戳、故障类型、通道状态），支持事故追溯分析。
I.Product Positioning and Core Functions
1.Target Application Scenarios
Petrochemical Plant Safety Control:
Used in high-risk process units such as catalytic cracking,hydrocracking,and ethylene cracking,triggering emergency shutdown(ESD)under abnormal operating conditions such as overtemperature,overpressure,and leakage to prevent catastrophic accidents such as explosions and fires.
Natural Gas Processing and Transportation:
In natural gas compression stations and pipeline pressure regulating stations,this system monitors pressure,flow,and combustible gas concentration,and controls ignition,flameout,and gas shutoff via the combustion management system(BMS)to ensure safe equipment operation.
Nuclear Power Plant Auxiliary Systems:
Used for safety-level control of critical equipment such as nuclear reactor coolant pumps and steam generators,meeting the requirements of IEC 61513(Nuclear Power Plant Safety System Standard).2.Core Functions
Triple Modular Redundant(TMR)Architecture:
The module integrates three independent channels(A/B/C),each containing a CPU,I/O,and communication interfaces.A voting mechanism(2/3 logic)achieves fault tolerance.Even if a single channel fails,the system maintains undisturbed operation,preventing unexpected or missed shutdowns.
High-Speed Fault Detection and Diagnosis:
Supports real-time self-diagnosis(e.g.,power supply,communication,and sensor faults)with a detection time of less than 10ms.Fault information is uploaded to the operator station via HART or Modbus,guiding rapid maintenance.
Safety Integrity Level(SIL)Certification:
Certified by TÜV Rheinland,Exida,and other organizations,this system complies with IEC 61508(functional safety standard)and ISA S84(process industry safety standard),achieving SIL 3 safety functions(risk reduction factor>1000).Hot-Swap and Online Replacement:
Modules support hot swapping,allowing faulty modules to be replaced without downtime,reducing unplanned downtime and improving system availability(>99.999%).
II.Technical Specifications and Performance Parameters
1.Hardware Specifications
Processor Performance:
Each channel is equipped with a 32-bit RISC processor with a main frequency of 200MHz and a processing capacity of>1000 instructions/ms,meeting the requirements of high-speed safety logic operations(such as PID control and interlocking logic).
I/O Capacity:
Digital Input(DI):Supports 24V DC signals,up to 32 channels per module,with a response time of<1ms.
Digital Output(DO):Supports relay or solid-state outputs,up to 16 channels per module,with a load capacity of 2A/24V DC.
Analog Input(AI):Supports 4-20mA and 0-10V signals,up to 8 channels per module,with an accuracy of±0.1%FS and a sampling rate of 100 times/second.Communication Interfaces:
Front panel:1 RS-485 port(Modbus RTU protocol)for communication with third-party devices.
Rear panel:1 Ethernet port(100 Mbps,redundant configuration)supports Triconex proprietary protocols for real-time data exchange with engineering and operator stations.
Environmental Adaptability:
Operating Temperature:-20°C to+70°C(industrial grade),optional-40°C to+85°C(extended grade),suitable for outdoor and extreme environments.
Protection Rating:IP66(dustproof and waterproof),complies with NEMA 4X standards,suitable for locations exposed to corrosive gases or moisture.
2.Software Features
Safety Logic Programming:
Using Triconex TriStation 1131 software,support for IEC 61131-3 standard programming languages such as Function Block Diagram(FBD),Ladder Diagram(LD),and Sequential Function Chart(SFC)simplifies safety logic development.Online Debugging and Simulation:
Offline simulation functionality allows you to simulate input signals on a PC to verify the correctness of safety logic and reduce on-site debugging time.
Historical Data Logging:
Built-in non-volatile memory(NVM)records the last 1,000 fault events(including timestamp,fault type,and channel status),supporting incident retrospective analysis.
