描述
一、产品定位与核心功能
模块类型
-温度输入模块（AI）：支持热电偶（TC）或RTD（铂电阻）信号采集，集成于Triconex TMR（三重模块化冗余）安全控制系统。
核心功能
-信号处理：支持多种温度传感器输入（如J/K型热电偶、Pt100/Pt1000 RTD）；
-冗余设计：三重化架构确保单点故障不影响系统运行，支持通道隔离与故障自诊断；
-环境适应性：宽温工作范围，抗振动与电磁干扰（EMC）。
二、关键技术参数（推测，基于Triconex同类模块）
|项目|参数/功能|
|输入类型|热电偶（J/K/T/E）、RTD（Pt100/Pt1000）|
|通道数|8通道（典型配置）|
|精度|±0.2°C（RTD模式），±1°C（热电偶模式）|
|响应时间|<50ms|
|隔离能力|每通道独立隔离|
|安全认证|SIL 3（配合TMR系统）|
|工作环境|-40°C至+70°C|
三、版本REVD的改进重点
型号后缀REVD通常表示硬件或固件的修订版本，可能包含以下优化：
信号稳定性：改进低温环境下热电偶的噪声抑制；
诊断功能：新增传感器断线检测与补偿算法；
兼容性：适配Triconex新一代主控制器（如MP3301）。
1.Product positioning and core functions
Module Type
-Temperature input module(AI):supports thermocouple(TC)or RTD(platinum resistor)signal acquisition,integrated into Triconex TMR(triple modular redundancy)safety control system.
Core functions
-Signal processing:Supports multiple temperature sensor inputs(such as J/K thermocouple,Pt100/Pt1000 RTD);
-Redundant design:the triple architecture ensures that single point of failure does not affect the system operation,and supports channel isolation and fault self-diagnosis;
-Environmental adaptability:Wide temperature working range,anti-vibration and electromagnetic interference(EMC).
2.Key technical parameters(presumably based on similar modules of Triconex)
|Project|Parameters/Functions|
|Input Type|Thermocouple(J/K/T/E),RTD(Pt100/Pt1000)|
|Number of channels|8 channels(typical configuration)|
|Accuracy|±0.2°C(RTD mode),±1°C(thermocouple mode)|
|Response time|<50ms|
|Isolation capability|Independent isolation per channel|
|Safety certification|SIL 3(with TMR system)|
|Working Environment|-40°C to+70°C|
3.Important focus of improvement of version REVD
The model suffix REVD usually represents a revision of the hardware or firmware and may include the following optimizations:
Signal stability:Improve noise suppression of thermocouples in low temperature environments;
Diagnostic function:Added sensor disconnection detection and compensation algorithm;
Compatibility:Adapt to Triconex’s new generation main controller(such as MP3301).
