TRICONEX CM2201 7400206-100产品详情
TRICONEX CM2201 7400206-100是英维思（Invensys）Triconex安全仪表系统中的数字输出模块（DO），专为高可靠性工业控制设计，适用于石油、化工、电力等需冗余容错的场景。以下是综合多来源技术文档及供应商信息的详细说明：
一、产品定位与核心功能
模块类型
-数字输出模块（DO）：提供16路独立开关量输出，支持设备控制（如阀门、报警器）及系统联锁。
核心功能
-冗余设计：采用三重模件冗余（TMR）架构，三套独立电路并行运行，通过表决机制确保输出一致性；
-高负载能力：每路输出支持24VDC电压、2A电流，负载电阻范围100Ω；
-自诊断与保护：实时监测短路、过载等故障，自动隔离异常通道并记录日志。
二、关键技术参数
|项目|参数/功能|
|————————|—————————————-|
|输出通道|16通道（独立隔离）|
|输出类型|开关量（晶体管型）|
|电压/电流|24VDC±10%，2A/通道|
|负载电阻|100Ω（推荐）|
|环境条件|工作温度：-40°C至+70°C；湿度：20%–95%（非冷凝）|
|尺寸/重量|120×80×40mm，0.5kg|
|兼容协议|Triconex EUCN（增强通用控制网络）|
三、典型应用场景
工业控制
-控制阀门开关、设备启停（如泵、电机）；
-触发报警信号（如火灾报警系统）。
安全联锁
-紧急停车（ESD）系统中执行安全动作，确保SIL 3等级安全。
TRICONEX CM2201 7400206-100 Product Details
TRICONEX CM2201 7400206-100 is a digital output module(DO)in Invensys Triconex safety instrumentation system.It is specially designed for high-reliability industrial control and is suitable for scenarios such as petroleum,chemical industry,and electricity that require redundancy and fault tolerance.The following is a detailed description of the comprehensive multi-source technical documents and supplier information:
1.Product positioning and core functions
Module Type
-Digital output module(DO):Provides 16 independent switching outputs,supporting equipment control(such as valves,alarms)and system interlocking.
Core functions
-Redundant design:adopts triple module redundancy(TMR)architecture,three sets of independent circuits operate in parallel,ensuring output consistency through a voting mechanism;
-High load capacity:Each output supports 24VDC voltage and 2A current,and the load resistance range is 100Ω;
-Self-diagnosis and protection:Monitor short circuits,overloads and other faults in real time,automatically isolate abnormal channels and record logs.
2.Key technical parameters
|Project|Parameters/Functions|
|Output Channel|16 Channels(Independent Isolation)|
|Output type|Switch quantity(transistor type)|
|Voltage/Current|24VDC±10%,2A/Channel|
|Load Resistance|100Ω(recommended)|
|Environmental Conditions|Operating Temperature:-40°C to+70°C;Humidity:20%–95%(non-condensing)|
|Dimensions/Weight|120×80×40mm,0.5kg|
|Compatibility Protocol|Triconex EUCN(Enhanced Universal Control Network)|
3.Typical application scenarios
Industrial Control
-Control valve switches,equipment start and stop(such as pumps,motors);
-Trigger alarm signals(such as fire alarm system).
Safety interlock
-Safe actions are performed in the Emergency Parking(ESD)system to ensure SIL 3 level safety.
