TRICONEX DI2301 7400208-020产品详情
TRICONEX DI2301 7400208-020是英维思（Triconex）安全仪表系统中的数字输入模块（DI），专为高可靠性工业信号采集设计，适用于需冗余容错的石化、电力、化工等场景。以下是综合多来源技术文档及供应商信息的详细说明：
一、产品定位与核心功能
模块类型
-数字输入模块（DI）：负责采集现场开关量信号（如传感器、限位开关），支持安全联锁与过程控制。
核心功能
-信号采集：支持24VDC输入信号，兼容NAMUR或常规开关量；
-冗余设计：三重模件冗余（TMR）架构，三套独立电路并行运行并通过表决机制确保数据一致性；
-自诊断能力：实时监测通道状态，检测断线、短路等故障并触发报警。
二、关键技术参数
|项目|参数/功能|
|输入通道|16通道（独立隔离，部分版本标注23通道）|
|输入类型|漏型/源型兼容（支持PNP/NPN传感器）|
|电压/电流|24VDC±10%，最大输入电流20mA|
|响应时间|<10ms|
|隔离能力|每通道独立隔离（2500V AC）|
|环境条件|工作温度：-40°C至+70°C；湿度：20%–95%（非冷凝）|
|安全认证|SIL 3（IEC 61508）、IEC 61511|
三、典型应用场景
工业安全控制
-火气监测系统（F&G）中传感器信号采集；
-紧急停车（ESD）系统中设备状态监控。
过程自动化
-�石化工厂管道阀门位置反馈；
-发电设备运行状态监测。
TRICONEX DI2301 7400208-020 Product Details
TRICONEX DI2301 7400208-020 is a digital input module(DI)in Triconex safety instrumentation system.It is specially designed for high-reliability industrial signal acquisition and is suitable for petrochemical,electrical,chemical and other scenarios that require redundancy and fault tolerance.The following is a detailed description of the comprehensive multi-source technical documents and supplier information:
1.Product positioning and core functions
Module Type
-Digital input module(DI):Responsible for collecting on-site switching signals(such as sensors,limit switches),supporting safety interlocking and process control.
Core functions
-Signal acquisition:supports 24VDC input signal,compatible with NAMUR or conventional switching quantity;
-Redundant design:triple module redundancy(TMR)architecture,three sets of independent circuits operate in parallel and ensure data consistency through voting mechanism;
-Self-diagnosis capability:monitor channel status in real time,detect faults such as disconnection,short circuit,etc.and trigger alarms.
2.Key technical parameters
|Project|Parameters/Functions|
|Input channel|16 channels(independent isolation,23 channels marked in some versions)|
|Input type|Leakage/Source type compatible(supports PNP/NPN sensor)|
|Voltage/current|24VDC±10%,maximum input current 20mA|
|Response time|<10ms|
|Isolation capability|Independent isolation per channel(2500V AC)|
|Environmental Conditions|Operating Temperature:-40°C to+70°C;Humidity:20%–95%(non-condensing)|
|Safety Certification|SIL 3(IEC 61508),IEC 61511|
3.Typical application scenarios
Industrial safety control
-Sensor signal acquisition in the fire gas monitoring system(F&G);
-Equipment status monitoring in emergency parking(ESD)systems.
Process automation
-Feedback of the position of pipeline valves in petrochemical plants;
-Monitoring of the operating status of power generation equipment.
