VIBRO-METER VM600 RPS6U 200-582-500-013电源模块产品详情
1.产品概述
VM600 RPS6U 200-582-500-013是Vibro-Meter（现属Meggitt公司）推出的工业级机架电源模块，专为VM600系列机械保护与振动监测系统设计，提供稳定可靠的电力供应，支持多模块扩展和冗余配置。它适用于发电厂、石油天然气、化工等工业领域的设备监测与保护系统。
2.核心功能与特性
（1）电源输出与保护
输出电压：
+5 VDC和±12 VDC，为机架内模块（如MPC4机械保护卡、XIO16T输入/输出卡）供电。
过压/过载保护：
内置过压、短路、过载保护机制，确保系统稳定运行。
冗余配置：
支持单电源或双电源冗余供电（需配置两台RPS6U），提升系统可靠性。
（2）环境适应性
工作温度：-40°C至+80°C（宽温型），适应极端工业环境。
防护等级：符合IEC 60068标准，通过振动（0.35 mm峰值）、冲击（6g峰值）及跌落测试。
湿度与粉尘：支持5%～95%非冷凝湿度环境，防尘设计。
3.技术规格
参数描述
输入电压交流或直流输入（具体型号可能不同，需参考手册）
输出电流最大25A（直流输入时）
通信接口支持与VM600机架总线（如OC总线）通信，可扩展至其他模块。
平均无故障时间>40,000小时（70°C环境下）
安装方式19英寸机架式（6U高度），兼容ABE04x系列机架。
4.典型应用场景
发电厂：汽轮机、发电机振动监测系统的供电。
石油天然气：压缩机、泵类设备的保护与状态监测。
化工与冶金：离心机、风机等旋转机械的电力支持。
航空航天：关键设备振动检测系统的冗余电源配置。
VIBRO-METER VM600 RPS6U 200-582-500-013 Power Supply Module Product Details
1.Product Overview
VM600 RPS6U 200-582-500-013 is an industrial-grade rack power supply module launched by Vibro-Meter(now Meggitt).It is designed for the VM600 series mechanical protection and vibration monitoring system,providing stable and reliable power supply and supporting multi-module expansion and redundant configuration.It is suitable for equipment monitoring and protection systems in industrial fields such as power plants,oil and gas,and chemicals.
2.Core functions and features
(1)Power output and protection
Output voltage:
+5 VDC and±12 VDC,powering modules in the rack(such as MPC4 mechanical protection card,XIO16T input/output card).
Overvoltage/overload protection:
Built-in overvoltage,short circuit,and overload protection mechanisms ensure stable system operation.
Redundant configuration:
Supports single or dual power supply redundant power supply(requires two RPS6U)to improve system reliability.
(2)Environmental adaptability
Operating temperature:-40°C to+80°C(wide temperature type),suitable for extreme industrial environments.
Protection level:Complies with IEC 60068 standard,passed vibration(0.35 mm peak),shock(6g peak)and drop tests.
Humidity and dust:Supports 5%to 95%non-condensing humidity environment,dust-proof design.
3.Technical specifications
Parameter Description
Input voltage AC or DC input(specific models may be different,please refer to the manual)
Output current Maximum 25A(when DC input)
Communication interface Supports communication with VM600 rack bus(such as OC bus),and can be expanded to other modules.
MTBF>40,000 hours(at 70°C)
Installation mode 19-inch rack-mount(6U height),compatible with ABE04x series racks.
4.Typical application scenarios
Power plants:Power supply for turbine and generator vibration monitoring systems.
Oil and gas:Protection and condition monitoring of compressors and pumps.
Chemical and metallurgical:Power support for rotating machinery such as centrifuges and fans.
Aerospace:Redundant power supply configuration for vibration detection systems of key equipment.
