描述
产品简要说明
VMIC 360-010050-000是一款面向工业自动化领域的高可靠性电源适配器，核心特性包括：
宽幅输入电压：85-264Vac全范围支持，兼容单相/三相电网
高精度输出：24Vdc±1%，纹波≤50mV
极端环境适应性：-40℃～+70℃无风扇散热，IP67防护等级
智能冗余保护：三级过温保护（85℃降载、95℃关断、105℃锁定）
产品详细说明
1.硬件架构与核心技术
LLC谐振拓扑架构
效率优化：采用软开关技术降低开关损耗，效率≥92%（80 PLUS铂金认证）
自适应调节：谐振频率动态匹配50Hz/60Hz电网波动，电压波动容忍±10%
三级EMI滤波网络
干扰抑制：差模/共模双层滤波，传导干扰抑制≥60dB（150kHz-30MHz）
标准符合：EN 55032 Class B，适配医疗设备等严苛电磁环境
智能冗余保护系统
输入保护：过压/欠压触发阈值±20%Ue，支持APC Smart-UPS SRT 3000VA稳压器
输出保护：过流/短路自动重启（延迟5秒），支持VMIVME-7807RC电源模块冗余配置
产品概述:VMIC 360-010050-000
作为工业电源领域的核心组件，其核心价值体现在宽幅输入与极端环境适应性：
技术价值：
在风电系统中为塔筒传感器提供-40℃～+70℃稳定供电
在地铁隧道环境中实现IP67防护等级下的长期运行
行业适配：
新能源：光伏逆变器控制柜供电、动力电池BMS电源保障
轨道交通：车载设备电源冗余、信号机柜抗震动设计
智能制造：工业机器人伺服驱动、数控机床控制单元供电
技术规格:VMIC 360-010050-000
参数项规格描述
输入电压85-264Vac（单相/三相兼容）
输出电压24Vdc±1%（纹波≤50mV）
额定功率150W（支持100%-120%瞬时过载）
效率≥92%（80 PLUS铂金认证）
工作温度-40℃～+70℃（无风扇散热）
防护等级IP67（全密封结构，防尘防水）
核心价值与性能亮点
1.宽幅输入兼容性
技术优势：全范围85-264Vac输入，适应偏远地区电网波动
应用案例：某高原风电场在电压波动±15%环境下稳定运行
2.军工级环境适应性
技术优势：IP67防护+无风扇散热设计，通过振动测试5g 20-2000Hz
价值体现：某地下矿井设备在粉尘/潮湿环境中连续运行5年零故障
3.智能冗余保护创新
技术优势：三级过温保护+自动重启机制，避免系统级宕机
行业应用：某核电站安全监控系统实现供电故障零影响
Product brief description
VMIC 360-010050-000 is a high-reliability power adapter for the industrial automation field,with core features including:
Wide-format input voltage:85-264Vac full range support,compatible with single-phase/three-phase grid
High-precision output:24Vdc±1%,ripple≤50mV
Extreme environmental adaptability:-40℃~+70℃fan-free heat dissipation,IP67 protection level
Intelligent redundancy protection:three-level overtemperature protection(85℃load reduction,95℃shutdown,105℃lockdown)
Product details
1.Hardware architecture and core technology
LLC resonant topology architecture
Efficiency optimization:Use soft switch technology to reduce switching losses,efficiency≥92%(80 PLUS Platinum Certified)
Adaptive adjustment:dynamically matches the 50Hz/60Hz power grid fluctuations,voltage fluctuations tolerate±10%
Three-level EMI filtering network
Interference suppression:Differential mode/common mode double-layer filtering,conduction interference suppression≥60dB(150kHz-30MHz)
Standard complies with:EN 55032 Class B,adapted to harsh electromagnetic environments such as medical equipment
Intelligent redundancy protection system
Input protection:overvoltage/undervoltage trigger threshold±20%Ue,support APC Smart-UPS SRT 3000VA regulator
Output protection:Overcurrent/short circuit automatic restart(delay of 5 seconds),support the redundant configuration of VMIVME-7807RC power module
Product Overview:VMIC 360-010050-000
As a core component in the industrial power supply field,its core value is reflected in wide-format input and extreme environmental adaptability:
Technical value:
Provide stable power supply for tower sensors in wind power systems-40℃~+70℃
Achieve long-term operation under IP67 protection level in subway tunnel environment
Industry adaptation:
New energy:Power supply for photovoltaic inverter control cabinet,power battery BMS power supply guarantee
Rail Transit:Redundant power supply of vehicle equipment,vibration-resistant design of signal cabinets
Intelligent manufacturing:power supply for industrial robot servo drive and CNC machine tool control unit
Technical Specifications:VMIC 360-010050-000
Parameters Specification Description
Input voltage 85-264Vac(single-phase/three-phase compatible)
Output voltage 24Vdc±1%(ripples≤50mV)
Rated power:150W(supports 100%-120%instantaneous overload)
Efficiency≥92%(80 PLUS Platinum Certified)
Working temperature-40℃~+70℃(fan-free heat dissipation)
Protection level IP67(full sealed structure,dustproof and waterproof)
Core Valuesand Performance Highlights
1.Wide input compatibility
Technical advantages:Full range of 85-264Vac inputs,adapting to power grid fluctuations in remote areas
Application case:A plateau wind farm operates stably under a voltage fluctuation of±15%
2.Military-grade environmental adaptability
Technical advantages:IP67 protection+fanless cooling design,passing vibration test 5g 20-2000Hz
Value manifestation:An underground mine equipment operates continuously in a dust/humid environment for 5 years and has zero failures
3.Intelligent redundancy protection innovation
Technical advantages:Level 3 overtemperature protection+automatic restart mechanism to avoid system-level downtime
Industry application:A nuclear power plant safety monitoring system achieves zero impact on power supply failure
