描述
WOODWARD 2301D是一款数字负荷分配和速度控制器，主要用于柴油机或气体机驱动的发电机组。以下是其产品详情：
功能特点：
多种工作模式：有速度控制、远程速度和负荷设定、同步负荷分配、掉速基载四种工作模式，可满足不同的应用需求。
动态控制功能：具有动态控制功能，可用于驱动泵或压缩机，还可通过可配置的4-20mA模拟量进行远程控制。
负荷分配与速度控制：能够提供精确的负荷分配和速度控制，兼容绝大多数现有的负荷分配速度控制系统，具备软加载和卸载功能。
参数配置灵活：可以使用伍德沃德Watch Window软件进行配置，通过控制器上的九针接口（RS-232接口）与电脑连接，可在软件中设置适当的发动机转速范围、齿数以及旋转方向等参数。
技术参数：
电源：24Vdc电源供电。
输入输出：包含1个负荷分配电路，1个执行器驱动器（4–20mA、0–20mA或0–200mA），1个磁电式转速传感器，1个可配置的模拟量输出，2个可配置的模拟量输入，8个开关量输入，4个继电器输出。
工作温度范围：–40到+70°C（–40到+158°F）。
ABB Model:GBU72 3BHE055094R0002 Model:3BHE055094R0002 GBU72 Model:GBU72 Model:3BHE055094R0002 Model:3BHE031197R0001 Model:3BHB030310R0001 Model:73BHE055094R0002 GBU72 Model:73BHE055094R0002 Model:GBU72 Model:ABB PCS6000 PRODUCT FAMLIY ABB 5SHY4045L0006 3BHB030310R0001 3BHE039203R0101 GVC736CE101
The WOODWARD 2301D is a digital load sharing and speed controller designed for diesel or gas engine-driven generator sets.Product details are as follows:
Features:
Multiple Operating Modes:Four operating modes are available,including speed control,remote speed and load setting,synchronized load sharing,and speed drop base load,to meet diverse application requirements.
Dynamic Control:Dynamic control is available for driving pumps or compressors,and remote control is possible via a configurable 4-20mA analog input.
Load Sharing and SpeedControl:Provides precise load sharing and speed control,compatible with most existing load sharing and speed control systems,and includes soft loading and unloading capabilities.
Flexible Parameter Configuration:Configuration is accomplished using Woodward Watch Window software,which connects to a computer via the controller’s nine-pin RS-232 interface.Parameters such as the engine speed range,number of teeth,and rotation direction can be set in the software.
Technical Parameters:
Power Supply:24VDC.
Inputs and Outputs:Includes one load sharing circuit,one actuator driver(4–20mA,0–20mA,or 0–200mA),one magnetic speed sensor,one configurable analog output,two configurable analog inputs,eight digital inputs,and four relay outputs.
Operating temperature range:–40 to+70°C(–40 to+158°F).
