描述
Woodward 5453-279NEW 5501-424D是Woodward公司生产的一款MicroNet TMR系列产品，具体详情如下：
基本信息
品牌：Woodward
型号：5453-279NEW/5501-424D
产地：美国
产品类型：MicroNet TMR 12槽底盘框架
HS编码：85389091
尺寸：约16cm×16cm×12cm
重量：约0.8kg
功能特点
TMR架构：支持三重模块化冗余（TMR）系统，确保高可靠性和容错能力，可作为关键系统组件（如核心电源、中央处理器和多达十二个I/O模块）的中央枢纽。
处理器兼容性：根据处理器类型不同，具有不同的扩展和I/O共享能力。与TMR 5200处理器配合使用时，可通过RTN网络实现I/O共享；与TMR 040处理器配合使用时，可通过收发器和电缆建立专用的I/O连接。
安全认证：当与MicroNet安全模块（MSM）结合使用时，MicroNet Plus和MicroNet TMR平台已通过TUV认证，符合IEC 61508第1-7部分中SIL-1、SIL-2或SIL-3安全等级要求。
编程软件：使用可配置的间隙/编码器软件，安全系统设计团队可确定最终的系统/软件架构。
面板设计：模块面板上有两个锁存螺丝，用于将模块固定在模块安装单元中，面板上还包含八个CPU LED、一个状态LED和一个停止/复位按钮。
The Woodward 5453-279NEW 5501-424D is a MicroNet TMR series product manufactured by Woodward.Detailed information is as follows:
Basic Information
Brand:Woodward
Model:5453-279NEW/5501-424D
Origin:USA
Product Type:MicroNet TMR 12-Slot Chassis Frame
HS Code:85389091
Dimensions:Approximately 16cm×16cm×12cm
Weight:Approximately 0.8kg
Features
TMR Architecture:Supports Triple Modular Redundancy(TMR)system,ensuring high reliability and fault tolerance.It serves as the central hub for critical system components,such as the core power supply,central processor,and up to twelve I/O modules.
Processor Compatibility:Expansion and I/O sharing capabilities vary depending on the processor type.When used with the TMR 5200 processor,I/O sharing is achieved via the RTN network;when used with the TMR 040 processor,dedicated I/O connections can be established via transceivers and cables.
Safety Certification:When used with the MicroNet Safety Module(MSM),the MicroNet Plus and MicroNet TMR platforms are TUV certified to meet the requirements of IEC 61508 Parts 1-7 for SIL-1,SIL-2,or SIL-3 safety levels.
Programming Software:Configurable gap/encoder software allows safety system design teams to determine the final system/software architecture.
Faceplate Design:The module faceplate features two locking screws to secure the module in the module mounting unit.The faceplate also includes eight CPU LEDs,a status LED,and a stop/reset button.
