WOODWARD 5461-002是伍德沃德（Woodward）公司推出的一款高性能工业继电器模块，专为复杂自动化系统设计，支持高可靠性信号切换与安全回路控制。以下是其核心功能与技术特性：
1.核心功能与技术参数
继电器输出类型：
提供8路独立继电器输出，支持常开（NO）、常闭（NC）及转换触点模式，单路额定电流10A 250V AC，适用于电机启停、电磁阀控制等场景。
通信接口：
集成RS-232/RS-485通信端口，支持Modbus RTU协议，可与PLC、DCS系统及上位机无缝对接。
防护与环境适应性：
工业级防护等级IP30，工作温度范围**-40°C至70°C**，宽温型号支持**-40°C至85°C**，抗电磁干扰能力符合IEC 61000标准。
2.技术优势
高可靠性设计：
采用冗余电源输入（12～48V DC），支持双路供电备份，MTBF（平均无故障时间）超过50,000小时。
内置硬件看门狗与过压保护电路，避免异常信号干扰导致误动作。
快速响应能力：
触点切换时间小于10ms，满足高速控制需求，例如伺服系统定位或紧急停机逻辑。
模块化扩展：
支持与Woodward其他模块（如5441-407、5453-278）协同工作，形成分布式控制系统。
3.应用场景
能源与动力系统：
作为柴油机调速器的紧急停机回路，响应传感器故障信号并切断燃油供应。
配合燃气轮机控制系统，实现安全联锁逻辑（如超温、超压保护）。
智能制造：
在机器人工作站中管理电机启停、夹具动作等离散控制任务。
在LED分拣设备中，控制剔除机构动作与生产线联动。
船舶工业：
集成于主机遥控系统，执行航行灯开关、舵机控制等安全关键指令。
WOODWARD 5461-002 is a high-performance industrial relay module launched by Woodward,designed for complex automation systems,supporting high-reliability signal switching and safety circuit control.The following are its core functions and technical features:
1.Core functions and technical parameters
Relay output type:
Provides 8 independent relay outputs,supports normally open(NO),normally closed(NC)and conversion contact modes,single-channel rated current 10A 250V AC,suitable for motor start and stop,solenoid valve control and other scenarios.
Communication interface:
Integrated RS-232/RS-485 communication port,supports Modbus RTU protocol,and can be seamlessly connected with PLC,DCS system and host computer.
Protection and environmental adaptability:
Industrial protection level IP30,operating temperature range**-40°C to 70°C**,wide temperature model supports**-40°C to 85°C**,and anti-electromagnetic interference capability complies with IEC 61000 standard.
2.Technical advantages
High reliability design:
Redundant power input(12~48V DC)is adopted,dual power supply backup is supported,and MTBF(mean time between failures)exceeds 50,000 hours.
Built-in hardware watchdog and overvoltage protection circuit to avoid abnormal signal interference and malfunction.
Fast response capability:
Contact switching time is less than 10ms,which meets high-speed control requirements,such as servo system positioning or emergency shutdown logic.
Modular expansion:
Supports collaboration with other Woodward modules(such as 5441-407,5453-278)to form a distributed control system.
3.Application scenarios
Energy and power system:
As the emergency shutdown circuit of the diesel engine speed governor,it responds to sensor fault signals and cuts off the fuel supply.
Cooperate with the gas turbine control system to realize safety interlock logic(such as over-temperature and over-pressure protection).
Intelligent manufacturing:
Manage discrete control tasks such as motor start and stop,fixture action,etc.in the robot workstation.
In LED sorting equipment,control the action of the rejection mechanism and the linkage with the production line.
Shipbuilding industry:
Integrated into the main engine remote control system to execute safety-critical commands such as navigation light switch and steering gear control.
