描述
easYgen 32000的主要功能
easYgen 32000作为3000系列的一员，将完整的发动机-发电机控制和保护与先进的并联功能相结合。
以下是其部分核心功能：
全面的发电机组控制和保护：
发动机控制：管理发动机启动/停止顺序（包括盘车控制和保护），可通过离散输入、接口或前面板启动/停止。支持各种发动机类型（柴油、汽油）。
发电机保护：包括针对发电机和主电源的各种电气保护功能，例如过流、欠压/过压、欠频/过频、逆功率和不平衡。
断路器控制：提供对发电机断路器(GCB)和主电源断路器(MCB)的控制，包括滑差频率/相位匹配同步、开/关控制和断路器监控等功能。
先进的并联功能：
多机组运行：可在点对点网络中控制和管理多达32台发电机组。
负载分配：支持有功功率(kW)和无功功率(kVAr)负载分配，确保并联发电机组之间的均衡功率分配。
同步：提供独立的相位匹配或滑差频率同步以及电压匹配，实现与电网或其他发电机的无缝连接。
负载相关启动/停止(LDSS)：根据负载需求、燃油效率、运行时间或其他可配置的优先级自动启动和停止发电机组，从而优化燃油消耗和维护。
灵活的电源管理：
运行模式：支持多种运行模式，包括自动、停止、手动和测试（负载/空载）。
负载转移：通过开/闭切换、互换、软加载/卸载以及市电并联操作，实现平稳的负载转移。
功率控制：支持kW、kVAr、V、f（频率）和PF（功率因数）控制，并提供基载运行和输出/输入控制选项。
直观的用户界面和通信：
内置人机界面(HMI)：配备5.7英寸背光彩色显示屏，并配有软键，方便用户直观操作和导航。可自定义的屏幕让用户轻松查看常用数据。
多种通信端口：配备丰富的通信选项，可集成到SCADA、楼宇管理系统和其他控制网络中：
以太网(Modbus TCP)
CAN总线（CANopen，用于发动机ECU的SAE-J1939协议）
RS-232
RS-485(Modbus RTU)
多语言功能：支持多种语言，方便全球用户使用。
坚固耐用的设计：
电源：12/24 VDC（8至40 VDC）供电。
环境适应性：设计用于宽工作温度范围（通常为-20至70°C，低温型号可扩展至-40°C），最高湿度可达95%（无凝露）。
安装方式：可选前面板安装（带显示屏）或机柜后部安装（不带显示屏）。
可配置逻辑：提供可自由配置的PID控制器和可定制的逻辑功能，适用于各种控制目的（例如，加热回路控制、水位、压力）。
Key Features of the easYgen 32000
The easYgen 32000,being part of the 3000 series,combines complete engine-generator control and protection with advanced paralleling functionalities.
Here are some of its core features:
Comprehensive Genset Control&Protection:
Engine Control:Manages engine start/stop sequences(including crank control and protection),can initiate start/stop via discrete inputs,interfaces,or the front panel.Supports various engine types(diesel,gas).
Generator Protection:Includes a wide range of electrical protection functions for the generator and mains,such as overcurrent,under/over voltage,under/over frequency,reverse power,and unbalance.
Circuit Breaker Control:Provides control for both Generator Circuit Breaker(GCB)and Mains Circuit Breaker(MCB)with features like slip frequency/phase matching synchronization,open/close control,and breaker monitoring.
Advanced Paralleling Capabilities:
Multi-Unit Operation:Can control and manage up to 32 generator sets in a peer-to-peer network.
Load Sharing:Supports real(kW)and reactive(kVAr)load sharing,ensuring balanced power distribution among paralleled gensets.
Synchronization:Offers independent phase match or slip frequency synchronization with voltage matching for seamless connection to the grid or other generators.
Load-Dependent Start/Stop(LDSS):Automatically starts and stops gensets based on load demand,fuel efficiency,service hours,or other configurable priorities,optimizing fuel consumption and maintenance.
Flexible Power Management:
Operating Modes:Supports various operation modes including Auto,Stop,Manual,and Test(Load/No Load).
Load Transfer:Facilitates smooth load transfers with open/closed transition,interchange,soft loading/unloading,and mains parallel operations.
Power Control:Enables kW,kVAr,V,f(frequency),and PF(power factor)control,with options for baseload operation and export/import control.
Intuitive User Interface&Communication:
Built-in HMI:Features a 5.7-inch back-lit color display with soft keys for intuitive user operation and navigation.Customizable screens allow users to visualize frequently used data easily.
Multiple Communication Ports:Equipped with extensive communication options for integration into SCADA,building management systems,and other control networks:
Ethernet(Modbus TCP)
CAN bus(CANopen,SAE-J1939 for engine ECUs)
RS-232
RS-485(Modbus RTU)
Multi-lingual Capability:Supports multiple languages for global usability.
Robust Design:
Power Supply:Operates on 12/24 VDC(8 to 40 VDC).
Environmental Resilience:Designed for a wide operating temperature range(typically-20 to 70°C,with low-temperature variants extending to-40°C)and up to 95%non-condensing humidity.
Mounting:Available for front panel mounting(with display)or cabinet back mounting(without display).
Configurable Logic:Offers freely configurable PID controllers and customizable logic functions for various control purposes(e.g.,heating circuit control,water level,pressure).
