描述
XMV16 600-003-VVV-VVV是Vibro-meter品牌VM600系列的振动监测模块，以下是其产品详情：
基本信息
品牌：Vibro-meter
型号：XMV16
子型号：600-003
类型：振动监测模块
尺寸：150mm×100mm×50mm
重量：0.5kg
电源：220V，50/60Hz
技术参数
通道数量：提供16个动态通道和4个转速计通道。
数据采集：24位数据采集，采用异步（固定频率）或同步（顺序跟踪）采样方式，可在所有通道上同时采集数据。
信号处理：高信噪比数据处理，FFT分辨率高达每1秒3200线。
转速测量：转速测量范围为1至100000rpm（0.017Hz至1.667kHz），分辨率为5ns。
通信协议：支持Modbus TCP/IP通信协议。
输入特性：转速计通道1和2支持电压和电流输入，通道3和4仅支持电压输入，电压范围为-20至+20VDC，电流范围为-30至+30mA。
产品特点
配置灵活：所有通道均可独立配置，每个动态通道和每个双通道最多有20个处理输出。
兼容性强：可与VM600系列的ABE040、ABE042、ABE056等机架兼容，且通常与XIO16T输入/输出模块配合使用。
分析功能强大：可实时采集振动的幅值、频率、相位等参数，并进行频谱分析、阶次跟踪等，帮助诊断设备的机械故障，如不平衡、不对中、轴承磨损等。
通信便捷：配备以太网连接器，可通过VibroSight软件与主机进行通信，实现数据的实时传输和分析。
The XMV16 600-003-VVV-VVV is a vibration monitoring module from the Vibro-meter brand VM600 series.The following are its product details:
Basic Information
Brand:Vibro-meter
Model:XMV16
Sub-model:600-003
Type:Vibration Monitoring Module
Dimensions:150mm×100mm×50mm
Weight:0.5kg
Power Supply:220V,50/60Hz
Technical Parameters
Number of Channels:Provides 16 dynamic channels and 4 tachometer channels.
Data Acquisition:24-bit data acquisition,using asynchronous(fixed frequency)or synchronous(sequential tracking)sampling,allowing simultaneous data acquisition on all channels.
Signal Processing:High signal-to-noise ratio data processing,with FFT resolution up to 3200 lines per second.SpeedMeasurement:The speed measurement range is 1 to 100,000 rpm(0.017 Hz to 1.667 kHz),with a resolution of 5 ns.
Communication Protocol:Supports Modbus TCP/IP communication protocol.
Input Characteristics:Tachometer channels 1 and 2 support voltage and current inputs,while channels 3 and 4 support only voltage inputs.The voltage range is-20 to+20 VDC,and the current range is-30 to+30 mA.
Product Features
Flexible Configuration:All channels are independently configurable,with up to 20 processing outputs per dynamic channel and per dual channel.
Compatibility:Compatible with VM600 series racks such as the ABE040,ABE042,and ABE056,and is typically used with the XIO16T input/output module.Powerful Analysis Capabilities:It collects vibration parameters such as amplitude,frequency,and phase in real time,and performs spectrum analysis and order tracking,helping to diagnose mechanical faults such as imbalance,misalignment,and bearing wear.
Convenient Communication:Equipped with an Ethernet connector,it communicates with a host computer via VibroSight software,enabling real-time data transmission and analysis.
